UL/ULC Listing Installation Addendum
Control Panel Model Advisor One (AVO-1037)
This addendum is a reference for basic installations according to UL requirements. Installation should only be performed by trained
technicians and the system should be serviced yearly or sooner as needed. Use UL listed and/or recognized wire. Follow standard
wiring practices.
Listings and Approvals
UL: ANSI/UL 985
ANSI/UL 1023
cUL: ULC S545
ULC/ORD-C1023
SIA: ANSI/SIA CP-01-2010
Electrical
AC Power: 120V 60Hz 550Ma to 12VDC, 2A Power Supply (P/N AVO-PS12V)
Rechargeable Backup Battery: 7,2VDC, 2800mAH NIMH (P/N AVO-BAT28A)
When fully charged, the battery will operate the panel without AC power for 24 hours with the panel in a normal, standby condition,
followed by 5 minutes in full alarm condition.
Note: Use UL listed and/or recognized wire. Use 2K Ohm End of Line resistors.
Installation Notes
•
UL has not evaluated inputs that program the safety aspects of the panel from remote sources. Use of any remote sources to
program the Fire or Security functions of the panel shall not be used. Application feature use has not been investigated by UL.
•
Only a single partition system is recognized by UL. Use only the US region.
•
Installer/dealer presence is required for the upgrade feature. Enterprise downloader has not been investigated for use by UL.
•
Auxiliary alarms not evaluated and are not to be used for UL 1637 (medical) applications.
•
CO Detector TX-6310-01-1 is Listed by ETL. Not evaluated to SIA Standards by UL.
•
Key Fob 600-1054-95R has not been investigated for use by UL.
•
Recent closing enabled (2-minute window).
•
Install according to NEC (NFPA 70) and any local ordinances.
14 / 18
Household Fire Warning
Household Burglar
Residential Fire Warning System Control Units
Preliminary Standard for Household Burglar Alarm System Units
False Alarm Reduction
AdvisorOne Panel Quick Installation Guide
