OWNERS MANUAL
ULTRA Single-Station Strength
G7-S73 Prone Leg Curl

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G7-S73 and is the answer not in the manual?

Questions and answers

Related Manuals for Matrix G7-S73

Summary of Contents for Matrix G7-S73

  • Page 1 OWNERS MANUAL ULTRA Single-Station Strength G7-S73 Prone Leg Curl...

  • Page 2: Table Of Contents

    Table Of Contents Safety, General Care & Maintenence ........................3 Getting Started (Product Specifications) ......................5 Assembly Information .............................6 Markings ..................................7 Parts List ...................................8 Installation & Assembly: Value Line Part 1 Weight Stack & Frame Assembly ....................10 Part 2 CAM & Cable Assembly ........................ 15 Part 3 Arm Assembly ..........................

  • Page 3: Safety, General Care & Maintenence

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INFORMATION It is the sole responsibility of the purchaser of Matrix products to instruct all individuals, whether they are the end user or supervising personnel on proper usage of the equipment. It is recommended that all users of Matrix exercise equipment be informed of the following information prior to its use.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm. WARNING: SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS TO AVOID INJURY! Never allow children on strength training equipment. Teenagers must be supervised at all times while using this equipment.

  • Page 5: Getting Started (Product Specifications)

    GETTING STARTED EXERCISE PLACARD | PRODUCT SPECIFICATIONS | MAINTENANCE CHECKLIST EXERCISE PLACARD PRODUCT SPECIFICATIONS TECH SPECS Maximum User Weight 136 kg / 300 lbs. Maximum Training Weight 91 kg / 200 lbs. Product Weight 264 kg / 581 lbs. Overall Dimensions (L x W x H) 173.2 x 110.5 x 129.6 cm / 68.2"...

  • Page 6: Assembly Information

    Thank you for purchasing a Matrix product. This machine is an EN957-1 and EN957-2 compliant Class S product. Your Matrix product is inspected before it is packaged. It is shipped in multiple pieces to facilitate the compact packaging of the machine.

  • Page 7: Markings

    MARKINGS WARNING LABEL LOCATIONS Hazard warning sticker (faces rear)

  • Page 8: Parts List

    Parts List DESCRIPTION Weight Stack M10 Flat Washer M10 X 30L Socket Head Cap Screw Lower Connecting Tube Inner Frame Assembly M10 X 75L Socket Head Cap Screw M10 Nylock Nut M10 Saddle Washer Mid Connecting Tube User Frame Pulley Bracket Wave (Spring) Washer Washer (45 OD X 30.3 ID) Axle/ROM Assembly...
  • Page 9 Parts List DESCRIPTION M10 X 20L Button Head Cap Screws Torso Pad Chest Pad Left Front Shroud Rear Shroud Right Front Shroud M8 X 60L Socket Head Cap Screw Top Cap...

  • Page 10: Part 1 Weight Stack & Frame Assembly

    ASSEMBLY PART 1: USER FRAME ASSEMBLY STEP 1 | WEIGHT STACK INSTRUCTIONS & NOTES DESCRIPTION QUANITY Weight Stack M10 Flat Washer M10 X 30L SHC Lower Connecting Tube Install the user frame hardware as shown, but DO NOT FULLY TIGHTEN .
  • Page 11 ASSEMBLY PART 1: USER FRAME ASSEMBLY STEP 2 | USER FRAME INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 Flat Washer M10 X 30L SHC Inner Frame Assembly M10 X 75L SHC M10 Nylock Nut M10 Saddle Washer View A • Ensure that the frame is level and that all floor pads contact the floor equally • Install the frame hardware as shown, orienting the saddle washers as shown in View A.
  • Page 12 ASSEMBLY PART 1: USER FRAME ASSEMBLY STEP 3 | FOOT PLATE ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 X 30L SHC M10 Saddle Washer Mid Connecting Tube Install the user frame hardware as shown, but DO NOT FULLY TIGHTEN .
  • Page 13 ASSEMBLY PART 1: USER FRAME ASSEMBLY STEP 4 | FOOT PLATE COVER ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 X 30L SHC M10 Saddle Washer User Frame View A • Ensure that the frame is level and that all floor pads contact the floor equally • Install the frame hardware as shown, orienting the saddle washers as shown in View A.
  • Page 14 ASSEMBLY PART 1: USER FRAME ASSEMBLY STEP 4 | FOOT PLATE COVER ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 Flat Washer M10 X 75L SHC M10 Nylock Nut Pulley Bracket Torque to 77 N-m/57 ft-lbs.

  • Page 15: Part 2 Cam & Cable Assembly

    ASSEMBLY PART 2: CABLE ASSEMBLY STEP 1 | CAM ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY Wave (Spring) Washer Washer (45 mm OD X 30.3 mm ID) Axle/ROM Assembly 13 14 • Remove CAM plate as shown - NOTE: two hex wrenches are required. Set hardware aside to be used later • Assemble Axle/ROM assembly and CAM; orient CAM as shown • Assemble cable onto CAM groove...
  • Page 16 ASSEMBLY PART 2: CABLE ASSEMBLY STEP 2 | CABLE ASSEMBLY INSTRUCTIONS & NOTES • Capture cable end with retaining clip • Assemble Key into Axle/ROM as shown • Using two hex wrenches, reassemble CAM plate and torque fasteners to: 39 N-m/29 ft-lbs. • Torque M10 center bolt to: 77 N-m/57ft-lbs.
  • Page 17 ASSEMBLY PART 2: CABLE ASSEMBLY STEP 3 | CAM GUARD ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 X 20L SHC Black Pivot Cap Ring M8 X 15L SHC M8 Flat Washer Guard Spacer Torque M10 hardware to 77 N-m/57 ft-lbs. Torque M8 hardware to 39 N-m/29 ft-lbs.

  • Page 18: Part 3 Arm Assembly

    ASSEMBLY PART 3: ARM ASSEMBLY STEP 1 | ARM ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 X 20L SHC Exercise Arm M10 Flat Washer (42 mm Dia.) Orange Pivot Cap 24 25 Torque to 77 N-m/57 ft-lbs.
  • Page 19 ASSEMBLY PART 3: ARM ASSEMBLY STEP 2 | AXLE ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY Axle...
  • Page 20 ASSEMBLY PART 3: ARM ASSEMBLY STEP 3 | ROM ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 Flat Washer M10 Nylock Nut ROM/Pad Assembly M10 X 130L SHC Torque to 77 N-m/57 ft-lbs.
  • Page 21 ASSEMBLY PART 3: ARM ASSEMBLY STEP 4 | COUNTER WEIGHT ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M8 Flat Washer M8 X 20L SHC Counter Weight Tighten to 39 N-m/29 ft-lbs.

  • Page 22: Part 4 Pad Assembly

    ASSEMBLY PART 4: PAD ASSEMBLY STEP 1 | ARM PAD ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY Arm Pad M10 X 20L BHC Orient the pads as shown. Tighten to 27 N-m/20 ft-lbs.
  • Page 23 ASSEMBLY PART 4: PAD ASSEMBLY STEP 2 | PAD ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M10 X 20L BHC Torso Pad Chest Pad Install the pads as shown. Tighten to 27 N-m/20 ft-lbs.

  • Page 24: Part 5 Plastics Assembly

    ASSEMBLY PART 5: PLASTICS ASSEMBLY STEP 1 | SHROUD ASSEMBLY ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY Left Front Shroud Rear Shroud Right Front Shroud Install the weight stack shrouds as shown.
  • Page 25 ASSEMBLY PART 5: PLASTICS ASSEMBLY STEP 2 | TOP CAP ASSEMBLY INSTRUCTIONS & NOTES DESCRIPTION QUANITY M8 X 60L SHC Top Cap Install the top cap and connect rep counter plug as shown. Torque to 17 N-m/147 in-lbs. I M PO RTA NT NOTI CE Position top cap so Rep Counter faces the user.
  • Page 26 Matrix Fitness 1600 Landmark Drive Cottage Grove WI 53527 matrixfitness.com Toll-free 866.693.4863 Facsimilie 608.839.8687 ULTRA Prone Leg Curl Owners Guide rev.1.2 Copyright© 2014 Matrix Fitness...
