Passport Solo and Duo Table Installation Instructions

Release date: 9/12/13

For installation assistance, call the following numbers:

Between 8:00am and 5:00pm (Eastern time): 1-800-NUCRAFT (1-800-682-7238)

Between 5:00pm and 8:00pm (Eastern time): 1-888-886-2028

Need help?

Do you have a question about the passport solo and is the answer not in the manual?

Questions and answers

Summary of Contents for Nucraft passport solo

Page 1 Passport Solo and Duo Table Installation Instructions Release date: 9/12/13 For installation assistance, call the following numbers: Between 8:00am and 5:00pm (Eastern time): 1-800-NUCRAFT (1-800-682-7238) Between 5:00pm and 8:00pm (Eastern time): 1-888-886-2028...
Page 2 Tools Required and Initial Notes Hardware Included Tools Required For Assembly 2 People SCREW, #12 x 1” PAN-PHIL – Zinc Plated • • • Phillips Head Screwdriver Draw-Tight Hardware • Drill with #2 and #3 Phillips Bit • • Brake Caliper – On Table Small Crescent Wrench or Open Face •...
Page 3 Passport Solo Table...
Page 4 Passport Duo Table...
Page 5 Passport Table Exploded Passport Component Description 1. Table Top 2. Table Base 3. Brake Caliper 4. Wire Manager 5. Table Stop Bracket with Shock Absorber 6. Brake Handle...
Page 6 Installation Prep – For Tables Larger than 156” • The beams will be split in the center and will need to be put together before following the instructions on the next page. Remove the bolts from the male • section of the beam, slide the male and female pieces together per the numbered stickers and fasten using the 3/8”...
Page 7 Installation Prep – For Tables Larger than 144” • The beams and end caps will ship separate from the table base. Locate the beam with the “V” roller • track and slide it on the “V” rollers on the table base. This beam will stay on the base without being held.
Page 8 Installation Step 1 Clamp to Secure rail • Locate the table base in the desired from moving location on the floor and remove all base panels. For Duo tables run each table frame to • Flush indicates end of travel. the center (toward end of travel) until end of travel is reached which is indicated in the top left photo with the...
Page 9 Installation Step 2 – Anchoring the table to the floor • Anchor the base to the floor using the anchor brackets and 3/8” cement anchors. Use a 3/8” masonry bit to drill an anchor hole 1-1/2” to 2” into the floor, pound in the anchor and attach using the 3/8”...
Page 10 Installation Step 3 – Last Steps Prior to Table Top Installation Route any power and data cables • through the wire manager prior to installing the table top whenever possible. • Install all other A/V equipment in the table base. If installing Dialogue connect the dialogue cables to the power cove connectors on the dialogue box.
Page 11 Installation Step 4 – Table Top Installation Prep • Attach the table stop bracket with the shock absorber on the underside of the table top in the pre-marked location. Use the #12 screw. (This may already be on the table depending on location and table size) Notice the small rectangular notch in •...
Page 12 Installation Step 5 – Attaching the table top Set the top on the base and align it • with the “L” shaped notches on the underside of the top. Be sure that the routed pocket for the brake handle is on the end of the table that has the brake cable and handle.
Page 13 Installation Step 6 –Brake Handle Fully extend the table to the end that • has the Brake handle pocket routed out in the top. • Locate the brake handle in the pocket with the flush side of the plate up. Place the brake handle cover over the plate and fasten using the supplied ¼-20 screws into the inserts in the...
Page 14 Installation Step 7 – Brake Caliper With the table still fully extended toward • the end with the brake handle, fasten one end of the caliper in the pre-marked location using the #12 Screws. Pull the brake handle and run the table all •...
Page 15 Installation Step 8 – Power Coves and Snake Install the power coves or Tech Nodes • into the top if they are not already installed. Follow the installation instructions provided with your power option. If your table has power coves with wood grain-matched doors please notice the lettered stickers on the cove correspond to lettered...
Page 16 Installation Step 9 – Wire Management If a Dialogue system is included • • Wire manage all wires to be tight to attach all Dialogue cables to the the underside of the table top so that Power Coves – It does not matter they will allow full travel of the table which cables go to which cove.
Page 17: Final Installation Steps
Final Installation Steps For duo tables be sure that the two • tables align in the center on the sides and the height of each table is very close to the same. Adjust the glides and base location to adjust alignment.
Page 18 A/V Additional Instructions To access the table base remove the • two flat side base panels. • To remove the wire manager remove the ¼-20 bolt that is fastening the snake to the table base and remove the screws that attach the snake to the underside of the table.
