Zaxcom Nomad User's Manual

Nomad Connector Assignments

Audio Input / Output Connectors (XLR-3)

Pin 1 – Ground
Pin 2 – Signal (+)
Pin 3 – Signal (-)

Audio Input / Output Connectors (TA-5)

Pin 1 - Ground
Pin 2 - Channel A (Left) ( + )
Pin 3 - Channel A (Left) ( - )
Pin 4 - Channel B (Right) ( + )
Pin 5 - Channel B (Right) ( - )
Mono & Tape Output Connectors (1/8" TRS)
Tip - +
Ring - N/C
Sleeve – Ground
NOTE: Since the ring connector is not being used, you can also use a TS plug.

Slate Microphone Input Connector (1/8" TRS)

Tip – ( + ) / Hot – biased to 5 Volts
Ring - ( - ) / Cold – Biased to 5 Volts
Sleeve - Ground
NOTE: This is a balanced input. It can be used with dynamic microphones. It can also be used unbalanced with
powered low voltage microphones.

Headphone Output Connectors (1/4" TRS or 1/8" TRS)

Tip – Signal Left
Ring – Signal Right
Sleeve – Signal ground

Power Connector (Hirose-4 Connector)

Pin 1 – Ground ( - )
Pin 2 – Not Connected
Pin 3 – Not Connected
Pin 4 – DC ( + )

GPI Remote Roll (USB Type A)

Pin 1 – Not Connected
Pin 2 – Not Connected
Pin 3 – Connect to one leg of the toggle switch
Pin 4 – Connect to the other leg of the toggle switch
(When the toggle switch is closed the circuit will be completed)
Connector Pin Assignments
73
