MAIN MENU

LCD Brightness

Adjusts the brightness of the LCD Screen.

LED Brightness

Adjusts the brightness of Nomad's LEDs. This is a global setting meaning that all LED lights will be set to the same
brightness.

Transport Keys

SHIFTED
If you press the TC, A-MIX or ZNET key, the pages associated with those keys will open. To go into Record mode,
Playback mode or Stop mode, it is necessary to SHIFT those keys. You will need to press the MENU knob to "SHIFT"
while simultaneously pressing the REC, PLAY or STOP key to go into that mode. This is the most popular choice.
NOTE: It is still possible to directly access the REC, PLAY and STOP functions by pressing the appropriate key for 1
second.
UNSHIFTED
Pressing the REC, PLAY or STOP key immediately puts the unit into Record mode, Playback mode or Stop mode. To
display the pages associated with the TC, A-MIX or ZNET key, it is necessary to press the MENU knob while pressing the
TC, A-MIX or ZNET key.

Tone Frequency

Adjusts the frequency of the reference tone. The range is 20 to 20,000 Hz.

Tone Level

Adjusts the output level of reference tone. The range is -90 to 0dB
NOTE: It is recommended to keep the tone level set at -20dB

AES 42

Turns on power for AES-42 microphones
ENG Setup / Advanced Setup
47
