NOMAD LAYOUT

Store/Recall a Home Screen Configurations

You can "park" two home screens for a quick recall of the Home Screen.
• To store a configuration under the COM key, press and hold the MENU knob, and press the COM key. Every time
you press the COM key, the next configuration in sequence is displayed. When you are happy with the
configuration being displayed, release the MENU knob.
• Repeat the process with the SLT key.
• To return to the saved COM key setting, press the MENU knob and COM key together.
• To return to the saved SLT key position, press the MENU knob and SLT key together.
4 Out over 4 In
6 Output Busses with Input Trim
Auto-Mix Meter Screen
Output Busses 1-4
Inputs 1-4
6 Output Busses
Auto Trim Meter
Output Bus 1 (Auto-Mix Output)
Auto-Mix Inputs - "A" designates inputs
assigned to Auto-Mix. Blue dot shows which
inputs are "open"
13
Meters
