MAIN MENU

Group Code

Sets which Group ID number Nomad will control.
This allows Nomad to control specific transmitters. For example, setting a Group Code to 1 allows you to control all
Group 1 transmitters. Setting it to 2 allows you to control all Group 2 transmitters. Group codes can be set from 1 to 99

TX Power

This adjusts the transmit power of the ZaxNet transmitter. Power range is 0 through 7 with 7 being the highest.

Transport Commands

If set to SLAVED, the Zaxcom wireless transmitters will start/stop recording each time Nomad starts/stops recording.

Power-Roll Mode

This setting is for the Zaxcom wireless transmitters that have a variable transmitter power setting:
• ALWAYS LOW – the transmitter will always be at the low power setting.
• DYNAMIC– the transmitter will run at low power between takes and go into high power when Nomad goes into
record.
• ALWAYS HIGH – the transmitter will always be run at the high power setting.

TRX Off-On

This controls the current power status for each Zaxcom wireless transmitters power:
• ON – the transmitter is fully ON.
• WAKE UP – wakes up any transmitters that were previously powered down in the LOW (OFF) setting.
• LOW (OFF) – disables the RF Power Amplifier, RF Board and Mic Pre-amp. The will cut the power consumption and
extend the battery life.

IFB Test Tone

This turns ON/OFF a test tone that is transmitted on the IFB audio channel to Zaxcom ERX receivers.

Burn ZaxNet Software

This menu allows you to install and updates the ZaxNet software.
The ZaxNet software is embedded within the Nomad software.
IFB Debug
This page is used for factory testing of the IFB.
41
ZaxNet Settings
