Using The Auto-Mixer - Zaxcom Nomad User Manual

MAIN MENU

Using The Auto-Mixer

• The Auto-Mixer menu can be accesses from the Main Menu. After the Auto-Mixer is enabled you can the access the
menu by pressing the A-MIX key on Nomad. Unless MP3 support is turned on, in that case the A-Mix key toggles the
MP3 recording marker.
• After your inputs are assigned to the Auto-Mixer the letter "A" will appear to the right of the meter for that input.
• When that input is active the "A" will be replaced by a blue dot indicating that the input is being included in the mix.
• If return inputs (7-10) are being used the virtual fader will appear over the meters for those inputs. To adjust the
levels on those inputs press the Menu knob to highlight that fader. Then by rotating the menu knob will adjust the
level to that input. To advance to the next fader press the menu knob. Press the back (headphone) knob to return to
normal operations or adjust the hardware fader for a different input. If any of the virtual fader are being used the
Menu knob must be held for 1 second in order to access the Main Menu.
• The Auto-Mix output will default to Output Bus 1. Most users will want to make sure all Bus routing is cleared for
Output Bus 1 to prevent unwanted audio from mixing into the bus.
IMPOTRANT: Auto - Mix will not be able to differentiate between a speaker's voice and noise such as a hit to the
microphone. So if the noise is louder than the Mic On Threshold that microphone will engage.
39
Mode Settings
Auto-Mix indicator
Active channel indicator
Virtual faders
