Zaxcom Nomad User Manual page 13

NOMAD LAYOUT
Card Track Home Screen
Card Meters w/ Output Bus
2 Output over 6 Input Home Screen
Virtual Fader Home Screen
Yellow ISO Attenuation Enabled Indicators
Red Record Enabled Indicators – Show which
tracks will be recorded
Card Meter Tracks
Yellow Strike Through – Represents that
these tracks will not be recorded
Output Busses 1 and 2
Card Meter Tracks
Output Buses 1 and 2
Input signal from XLR Inputs
Output busses 1 and 2
Line level inputs 7 through 10 with virtual
fader control
Auto Trim Meter
12
Meters
