Specifications
Display Specifications
LCD Module
Diagonal:
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
Grayscale Tones
Synchronization Range Horizontal:
Vertical:
Viewing Angle
Left/Right:
Up/Down:
Image Formation Time
Active Display AreaPortrait: Horiz.: 325 mm/12.8 inches
Landscape: Horiz.:
Power Supply
Current Rating
Dimensions
Portrait:
Landscape:
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Humidity:
Storage Temperature (in package):
Humidity (in package):
Feet (in package):
UL-Classification
According to the type of protection against electric shock: CLASS I
According to the degree of protection against electric shock: No Patient connection
According to the degree of protection against ingress of water as detailed in the current edition of IEC529: No Protection
According to the method of sterilization or disinfection recommended by the manufacturer: Not Specified
According to the degree of safety of application in the presence of a FLAMMABLE AN AESTHETIC MIXTURE WITH AIR or
a WITH OXYGEN OR NITROUS OXIDE: Not suitable
According to the mode of operation: Continuous operation
MD21GS-3MP Display
54 cm/21.3 inches
54 cm/21.3 inches
1536 x 2048 (Portrait)
2048 x 1536 (Landscape)
Video:
Digital Input: DVI
10 Bit:
1024 (10bit) shades of gray
from a pallet of 3061 (11.5bit)
8 Bit:
256 (8bit) shades of gray
from a pallet of 3061 (11.5bit)
31.5 kHz to 96.0 kHz
30 Hz, 50 Hz to 85 Hz
±88° (CR > 10)
±88° (CR > 10)
35 ms (Typ.)
Vert.:
433 mm/17.1 inches
433 mm/17.1 inches
Vert.:
325 mm/12.8 inches
AC 100-240V ~ 50/60Hz
0.7 - 0.35 A
358.7 mm (W) x 514 - 560 mm (H) x 200 mm (D)
14.1 inches (W) x 20.2 - 22.0 inches (H) x 7.9 inches (D)
467 mm (W) x 460 - 506 mm (H) x 200 mm (D)
18.4 inches (W) x 18.1 - 19.9 inches (H) x 7.9 inches (D)
46 mm/1.8 inches
11.7 kg/25.8 lbs
5°C to 40°C/41°F to 104°F
30% to 80% (without condensation)
Feet:
0 to 10,000 Feet/0 to 3,048 m
-20°C to 60°C/-4°F to 140°F
10% to 85% (without condensation)
0 to 40,000 Feet/0 to 12,192 m
English.9
1-32
Notes
Active matrix; thin film transistor (TFT) liquid
crystal display (LCD); 0.2115mm dot pitch;
400 cd/m
calibrated white luminance;
2
700:1 contrast ratio, typical.
VideoDot Clock 162Mhz Max
When used with an NEC recommended
10 bit display card
When used with an NEC recommended
8 bit display card
Automatically
Automatically
