- Page 1 BOOSTER PUMPS Models Nos: BPT600 & BPT1200SS Part Nos: 7237004 & 7237006 OPERATING & MAINTENANCE INSTRUCTIONS GC0711...
-
Page 2: Introduction
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 3: Table Of Contents
The BPT600 and BPT1200SS are centrifugal, horizontal, electric pumps with a self-priming capability and are designed with a venturi system, suitable for pumping water from up to 35 m height (BPT600) / 46 m height (BPT1200SS). They are designed to operate with clean water only at a maximum temperature of 35°C. -
Page 4: General Safety Precautions
GENERAL EQUIPMENT USE AND CARE WARNING: The BPT600 & BPT1200SS pumps are not submersible pumps. On no account should they ever be immersed in water. 1. ALWAYS maintain the pump with care and keep it clean. - Page 5 SERVICING 1. ALWAYS have the pump serviced by your local CLARKE dealer, using only identical replacement parts. This will ensure the safety of the pump is maintained. The use of non standard parts could be hazardous.
-
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the machine on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate using 230 VAC mains power. -
Page 7: Preparation For Use
PREPARATION FOR USE Accessories designed specifically for this range of pumps are available from your nearest CLARKE dealer. Contact your CLARKE dealer for further information, or CLARKE International Sales Department on 01992 565333. IMPORTANT: The pump MUST NOT be connected to the mains electrical supply until all hose/pipe installation is completed. - Page 8 • Position the pump as near to the water source as possible. • Ensure there is adequate drainage and there is no risk of damage to property as a result of water being discharged. • The performance of your pump will be affected by the diameter of the inlet pipe - any restriction will greatly reduce the flow.
- Page 9 1. Attach the foot valve to the end of the suction hose to prevent stones etc, from being drawn up, which could cause damage to the pump. Keep the foot valve clean. If it is likely to clog with dirt or debris, proceed by either: a.
-
Page 10: Operation
1. Remove the filler plug on top of the pump and slowly fill with water until all air is expelled. • Refilling is necessary only if the pump has been drained or if the water has been lost. Never allow the pump to run dry. 2. -
Page 11: Maintenance
MAINTENANCE For any problems requiring the dismantling and overhaul of the pump, contact your CLARKE International Service Department on 020-8988-7400. THE FILTER The separate inlet filter (Part number 7175100) supplied with these pumps will need regular cleaning out after use. Unscrew the filter bowl from the top section as in Fig 5 and wash out the bowl and filter element with clean, soapy water. -
Page 12: Troubleshooting
TROUBLESHOOTING . y l . y l l l i l i f . y l s l i f - l t t i . ) t l n i & l n i l n I n i l l n i t l i . - Page 13 TROUBLESHOOTING s i s l n i n i l . s r t i s n i l . r i . r i . y l . r i f i t & f i t . f f .
-
Page 14: Technical Specification
° 5 ° 5 Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. ACCESSORIES A wide range of airline accessories is available, including Filters, Foot Valves, Hoses, Couplings, etc. -
Page 15: Parts Lists And Diagrams
PARTS DIAGRAM-BPT600... - Page 16 PARTS LIST- BPT600 n i l f f i f f i & n i l - f l l n I...
- Page 17 PARTS DIAGRAM-BPT1200SS...
- Page 18 PARTS LIST- BPT1200SS n i l f f i f f i - f l & n i l - f l l n I...
-
Page 19: Declaration Of Conformity
DECLARATION OF CONFORMITY... - Page 20 DECLARATION OF CONFORMITY...
- Page 21 DECLARATION OF CONFORMITY...
- Page 22 DECLARATION OF CONFORMITY...
- Page 23 NOTES _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________...
