- Page 1 1” ELECTRIC WATER PUMP MODEL NO: BIP1000 PART NO: 7230330 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0521 - REV 5...
- Page 2 WHENEVER THERE IS A RISK OF PERSONAL INJURY. ENSURE THAT THESE WARNINGS ARE READ AND UNDERSTOOD AT ALL TIMES. Your CLARKE water pump has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local Clarke dealer.
-
Page 3: General Safety Precautions
9. NEVER use for pumping flammable liquids or corrosive chemicals. This pump is designed to pump clean water only. 11. ALWAYS have the pump serviced by your local Clarke dealer, using only identical replacement parts. This will ensure the safety of the pump is maintained. -
Page 4: Installation Of The Pump
WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. The BIP1000 pump will need to be fitted with a 1.5m length of 1.5mm flexible cable and a BS1363 approved plug. The plug will require connection to the cable in accordance with the diagram below. -
Page 5: Fitting The Cable
FITTING THE CABLE Do not attempt electrical installation work if you are in any doubt as to how it should be done correctly. Consult a qualified electrician. The pump must be wired according to the diagram, after removing the cover plate, ensuring the following principles are observed: •... -
Page 6: Pipe/Hose Connections
Plug must be BS1363/A approved. Always fit a 5 Amp fuse. Earth (Green and Yellow) Live Neutral (Brown) (Blue) Ensure that the outer sheath of the cable is firmly held by the clamp • Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. -
Page 7: Suction Lift Or Gravity Feed
The performance of your pump will be affected by the diameter of the inlet pipe - any restriction will greatly reduce the flow. We recommend that you always use a pipe diameter at least equal to, or greater than the diameter of the pump connections. -
Page 8: Priming The Pump
PRIMING THE PUMP Before pumping, you must completely fill the suction side with water to prime the pump which is carried out as follows:- 1. With all inlet pipes/hoses and foot valve in position, but no outlet hose connected, pour water into the outlet port until all the air is expelled. -
Page 9: Operation
1. Do not allow the pump to run dry, otherwise the seal between the pump and motor may be damaged. If a leak occurs at this point, allowing water to pass from the pump to the motor, take the pump to your Clarke dealer for overhaul. -
Page 10: Maintenance
The pump should not be taken apart by the user in the case of overhaul being required, but should be taken to your nearest Clarke dealer for specialist repair. AFTER USE After use, and if the pump will not be used over the winter period, or whenever there is danger of freezing, always drain the pump body. -
Page 11: Troubleshooting
Tighten as required. Air leaks through Renew seal. damaged seal. Impeller damaged and Return to your Clarke making poor seal. dealer for repair Impeller / mechanical Return to your Clarke seal is badly worn. dealer for repair. - Page 12 Installation of pump is Stop pump and unstable. re-position. Air pocket in pump or Release plug in impeller pipeline. housing to release air. Damaged impeller Return to your Clarke dealer for repair. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 13: Specification
SPECIFICATION Water Classification Clean Maximum Delivery 40 l/min Maximum Head 35 m Maximum Pump Speed 2720 rpm Maximum Lift (Suction) Operating Temperature 0-40 Overload type Thermal Cut-out Ingress Protection Rating IPx4 (splash proof) Operating Voltage & Frequency 230V / 50Hz Input Wattage@ Maximum Head 383 W Input Current@ Maximum Head... -
Page 14: Parts Diagram
PARTS DIAGRAM ID DESCRIPTION ID DESCRIPTION Screw M5 x 40 16 Cable Seal Pump Body 17 Cable Clamp Impeller 18 Terminal Block Screw M5 19 Seal 1 Motor Front Cover 20 Capacitor 8uf Ball Bearing 6201-Z2 21 Screw M4 Motor Rotor 22 Terminal Cover Motor Stator Coil 23 Connecting Wire... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
