Controls
– continued
Color Control System
Colour presets selects the desired colour setting. The bar is
replaced by the colour setting choice. Each colour setting is
adjusted at the factory to the stated Kelvin. If a setting is adjusted,
the name of the setting will change from Kelvin to Custom except
sRGB mode.
Red, Green, Blue: Color Control System decreases or increases
the monitor's red, green or blue colour guns depending upon which
is selected. The change in colour will appear on screen and the
direction (decrease or increase) will be shown by the bars.
sRGB mode: sRGB mode provides the suitable colour managed
picture image. You can not change Red, Green and Blue colours,
brightness and contrast individually.
Colour Temperature Adjustment: Adjusts the colour temperature
of the screen image.
Geometry Controls
Geometry Controls Menu
The Geometry controls allow you to adjust the curvature or angle
of the sides of your display.
Sides In/Out (pincushion): Decreases or increases the curvature
of the sides either inward or outward.
Sides Left/Right (pincushion balance): Decreases or increases
the curvature of the sides either to the left or right.
Sides Tilt (parallelogram): Decreases or increases the tilt of the
sides either to the left or right.
Sides Align (trapezoidal): Decreases or increases the bottom of
the screen to be the same as the top.
Rotate (raster rotation): Rotates the entire display clockwise or
counterclockwise.
Tools 1
Moiré Canceler: Moiré is a wavy pattern which can sometimes
appear on the screen. The pattern is repetitive and superimposed
as rippled images. When running certain applications, the wavy
pattern is more evident than in others. To reduce moiré, adjust the
level by using –/+ CONTROL buttons.
Tools 2
Language: OSM controls menus are available in 6 languages.
OSM Position: You can choose where you would like the
OSM controls menu to appear on your screen. Selecting
OSM Position allows you to manually adjust the OSM controls menu
position from among Center, Top left, Top right, Bottom left and
Bottom right.
OSM Turn Off: The OSM controls menu will stay on as long as it is
in use. In the OSM Turn Off sub-menu, you can select how long
the monitor waits after the last touch of a button for the OSM controls
menu to disappear. The preset choices are 5 thru 120 seconds.
ENERGYSTAR Product
As an ENERGYSTAR Partner,
NEC-Mitsubishi Electronics Display of America, Inc. has
determined that this product meets the ENERGYSTAR
guidelines for energy efficiency. The ENERGYSTAR emblem
does not represent EPA endorsement of any product or service.
4
OSM Lock Out: This control completely locks out access to all
OSM controls functions except Brightness and Contrast. When
attempting to activate OSM controls while in the lock out mode, a
screen will appear indicating that OSM controls are locked out. To
activate the OSM Lock Out function, press SELECT and hold +
down simultaneously. To deactivate the OSM Lock Out, press
SELECT and hold + down simultaneously.
IPM System Off Mode:
Enable:
The IPM System works normally and all stages of energy
savings are utilized.
Disable:
The Off Mode of the IPM System is not used.
NOTE:
For standard systems and graphics boards, keep the
factory setting at ENABLE.
Factory Preset: Selecting Factory Preset allows you a reset most
OSM control settings back to the factory settings. A warning
statement will appear to confirm that you do want to reset ALL
settings. Individual settings can be reset by highlighting the control
to be reset and pressing the RESET button.
Information
Display Mode: Indicates the current mode and frequency setting
of the monitor.
Monitor Info: Indicates the model and serial numbers of your
monitor.
Refresh Notifier: A message will advise you if the refresh rate of
the signal being applied to the monitor by the computer is too low.
For further information, please refer to your display card or system
manual.
Declaration of the Manufacturer
We hereby certify that the colour monitors
MultiSync FE770/FE771SB (N1702)
is in compliance with
Council Directive 73/23/EEC:
– EN 60950
Council Directive 89/336/EEC:
– EN 55022
– EN 61000-3-2
– EN 61000-3-3
– EN 55024
and marked with
NEC-Mitsubishi Electric Visual Systems Corporation
686-1, NISHIOI OI-MACHI
ASHIGARAKAMI-GUN
KANAGAWA 258-8533, JAPAN
