- Page 1 How to activate your Tunstall Liberty alarm - self-installation guide...
-
Page 2: Table Of Contents
Contents Your Tunstall Liberty alarm How to self-install your Tunstall Liberty alarm Step 1 Situate your alarm Step 2 GSM connection Step 3 Connect the mains power adaptor Step 4 Place a test call Step 5 Landline connection (optional) Contact details... -
Page 3: Your Tunstall Liberty 300 Alarm
Your Liberty base alarm unit Front view (Diagram 1) Mains power indicator Low battery indicator HELP (red) button CANCEL (green) button Display Diagram 1... - Page 4 Back view (Diagram 2) External GSM antenna HANDSET LINE IN POWER ETHERNET RS232 Battery switch Diagram 2...
-
Page 5: How To Self-Install Your Tunstall Liberty Alarm
How to self-install your Tunstall Liberty alarm Before you can start using your Tunstall Liberty alarm, please complete the following instructions. Please note: This alarm has been pre-programmed to automatically connnect to the Tunstall emergency response centre. DO NOT REPROGRAM THIS ALARM. - Page 6 0 to 9. 0-1 = Weak signal 2-5 = Average signal 6-9 = Strong signal Diagram 3 Note: A higher gain antenna is available for purchase for clients in poor GSM coverage areas. View Tunstall Healthcare contact details on page 12.
-
Page 7: Step 3 Connect The Mains Power Adaptor
Step 3 Connect the mains power adaptor Plug the black mains adaptor into the base alarm unit socket labelled ‘POWER’ (Diagram 4) and plug into a power point in your home (mains power). Turn on both the mains power and the battery switch on the alarm. Wait one minute for the alarm display to go blank. -
Page 8: Step 4 Place A Test Call
Step 4 Place a test call Press the blue button (Diagram 5) on your Liberty pendant to place a test call to the Tunstall response centre. Advise the response operator that you are installing your new Tunstall Liberty alarm. The response operator will confirm your details and complete the installation process with you. -
Page 9: Landline Connection (Optional)
Step 5 - Landline connection: (mains telephone line required) Complete this step if you are connecting your Liberty via a landline, with GSM as back-up only. Please disconnect the mains power and turn off the battery switch on your alarm before completing this step. Socket type selection Australian homes are fitted with one of two kinds of telephone wall socket connections. - Page 10 Type 1 - Modern RJ12 wall socket Connect the telephone line Unplug your existing telephone lead from your RJ12 wall socket. Plug the new white telephone line into the alarm unit socket labelled ‘LINE IN’, and then connect to your RJ12 wall socket (Diagram 8). LINE IN Diagram 8 Connect the telephone lead...
- Page 11 Type 2 - Traditional 610 wall socket Connect the telephone line Plug the new white telephone line into the alarm unit socket labelled ‘LINE IN’, and then connect to the front of the telephone adaptor (Diagram 10). LINE IN Diagram 10 Connect the telephone adaptor Unplug your existing telephone connector lead from the 610 wall socket, and replace with the telephone adaptor (Diagram 11).
-
Page 12: Contact Details
Tunstall Australasia t/a Tunstall Healthcare, 1/56 Lavarack Ave, Eagle Farm, QLD 4009 ABN 44 059 121 863 ACN 059 121 863 t: 1800 603 377 f: 07 3637 2255 e: customer.service@tunstallhealthcare.com.au w: www.tunstallhealthcare.com.au...
