BP7483-2 ASHLAND CF717.qxp_BP7483 12/15/15 9:55 AM Page 1
READ AND SAVE THESE INSTRUCTIONS
52" Ceiling Fan Owner's Manual
CF717BS01
Brushed Steel
Part No. F40BP74830002
Revision: 151201
ASHLAND
Model Numbers
CF717SW01
Satin White
Net Weight:
Questions, problems, missing parts: Before returning to the store call
Emerson Electric Customer Service
8 a.m. - 6 p.m., Eastern, Monday-Friday
1-800-654-3545
www.emersonfans.com
™
CF717ORB01
Oil Rubbed Bronze
19.5
Lbs.
• Español - página 29
• Français - page 57
Form No. BP7483-2
ETL Model No.: CF717-1
