- Page 1 READ AND SAVE THESE INSTRUCTIONS Model No. CF712AB00 CF712ORB00 CF712AW00 CF712WB00 CF712BS00 CF712WW00 CF712OB00 22.0 Net Weight: Lbs. ® PRO Series Ceiling Fan Owner's Manual Part No. F40BP73000001 Form No. BP7300-1...
-
Page 2: Safety Instructions
WARNING WARNING: To avoid fire, shock, and serious personal injury, follow these instructions. Safety Instructions 1. Read your owner’s manual carefully and keep it for future reference. 2. Before servicing or cleaning unit, switch power off at service panel and lock service panel disconnecting means to prevent power from being switched on accidentally. -
Page 3: Unpacking Instructions
This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly One Phillips head screwdriver One stepladder Installed Wire Length Wire Size A.W.G. One 1/4” blade screwdriver One wire stripper Up to 50 ft. -
Page 4: Removal Of The Hanger Bracket
Installing The Hanger IMPORTANT Ball/Downrod Assembly Your ceiling fan is designed to be installed either in the standard manner, or in the (For Standard Mounting) close-to-the-ceiling manner. Using the standard method, the hanger ball/downrod 1. Pass the 56" motor leads through the opening in assembly will suspend the fan several inches the ceiling cover. -
Page 5: Installing The Ceiling Cover On The Fan Motor Housing
Installing The Ceiling Cover WARNING On The Fan Motor Housing The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs. Use only a U.L. (For Close-to-the-Ceiling Mounting) outlet box listed as “Acceptable for Fan Support”. 1. -
Page 6: Electrical Requirements
Electrical Requirements Hanging The Ceiling Fan (Standard Method Using Your new ceiling fan will require a grounded electrical Hanger Ball/Downrod) supply line of 120 volts AC, 60 Hz, 15 amp circuit. The outlet box must be securely anchored and 1. Carefully lift the fan assembly and seat the hanger capable of withstanding a load of at least 50 pounds. -
Page 7: Installing The Fan Blades
2. Securely connect the fan motor white wire to the supply white (neutral) wire using wire connector REINSTALL SCREW AND TIGHTEN SCREW LOCKWASHER supplied (Figure 10). Securely connect the fan motor black wire and blue wire to the supply black (hot) wire using wire connector supplied (Figure 10). -
Page 8: Installing The Light Fitter
2. Mount one blade assembly to the motor hub by 5. Attach the switch housing cover with light fitter to mating the alignment post (Figure 12) of the flange the switch housing using the tree previously with one of the alignment slots in the motor hub removed screws. -
Page 9: Maintenance
9. Position the glass bowl over the threaded nipple Maintenance and seat bowl on bowl cap (Figure 16). Pass the fan pull chain through the bushing in the outer bowl cap and install the cap on the threaded nipple. IMPORTANT CARE INSTRUCTIONS Install nut finial finger tight. -
Page 10: Troubleshooting
WARNING: For your own safety, turn off power at fuse box or circuit breaker before trouble shooting your fan. Trouble Shooting TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers. 2. -
Page 11: Limited Warranty
LIMITED WARRANTY What The Warranty Covers: This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in workmanship and materials. You must be the original purchaser or user of the product to be covered. What The Period Of Coverage Is: As it applies to the motor, this warranty will last for fifteen years from the date you purchased your ceiling fan. -
Page 12: How To Order Repair Parts
Repair Parts Listing Model No. Description CF712AB00 CF712WW00 CF712AW00 CF712BS00 CF712WB00 CF712OB00 CF712ORB00 Hanger Pack Assembly, 762231 762231-1 762231-2 762231-4 762231-5 762231-7 762231-8 Consisting of: Hanger Bracket — — — — — — — Hanger Ball/ Downrod Assembly — —...
