Front Panel; Power Switch; Status Led - Solid State Logic XLogic Alpha-Link LIVE-R User Manual

Front Panel

Power Switch

Power Switch
This is used to switch the Alpha-Link LIVE-R on or off.
All front panel settings are stored in non-volatile memory ~5 sec after the last front panel change; please allow
time for this before switching the unit off.

Status LED

The STATUS LED will normally be extinguished. It will however flash under the following conditions:
• The Alpha-Link LIVE-R is in diagnostic mode (please refer to the System Settings and Diagnostics section).
• One of the two internal PSU units has failed (or is missing mains power) – firmware version V1.1 or later .
Routing Matrix Clock Source
Control Selection
Sample Rate
Selection
Signal Meters
Status LED
