b. If the unit is not set to lock to the interface in question and the interface provides multiple data formats ,
these options are used to set the 2Fs/4Fs data format for that interface:
• When set to 'Legacy (SMUX2 or SMUX4) a half-rate frame pattern will be used. This format is functionally
compatible with Fs rate interfaces and may be required to interface to older equipment.
• When set to 'High Speed' a proper 2Fs or 4Fs frame pattern will be used.
3. When both analogue and digital input groups are both connected to the MADI output groups, this option
determines which input group feeds the output group first and hence affects the order in which input channels
are assigned to channels on the MADI stream. Similarly, when the MADI input groups are routed to the analogue
output groups, this switch also determines the order in which the input channels are split across the selected
output groups. Please refer to the Routing Matrix Control section on page 6 for more detail.
4. Further to point 2. opposite, when Alpha-Link LIVE-R is set to lock to external wordclock whilst operating at 2Fs
or 4Fs, it may be necessary to inform the unit how to treat the applied clock signal if that signal is at Fs rate.
17
