Le Beffroi
Oil fired stove
Model 174 10 54
Description of the appliance
Installation instructions
Operating instructions
Spare parts
Warranty certificate
Document n° 954-6 ~ 29/04/2004
EN NO
Technical manual
to be saved
by the user
for future reference.
STAUB FONDERIE
Head Office Address
2, rue Saint Gilles
68230 TURCKHEIM
RC Colmar
SIREN 439 330 325
Address - Administration and
manufacturing
BP 73
59660 MERVILLE (FRANCE)
Telephone : 00 333 28 43 43 43
Fax : 00 333 28 43 43 99
Subject to modifications.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FRANCO BELGE 174 10 54 Le Beffroi
Summary of Contents for FRANCO BELGE 174 10 54 Le Beffroi
-
Page 1: Installation Instructions
Le Beffroi Document n° 954-6 ~ 29/04/2004 EN NO Oil fired stove Model 174 10 54 Technical manual to be saved by the user for future reference. STAUB FONDERIE Description of the appliance Head Office Address 2, rue Saint Gilles 68230 TURCKHEIM Installation instructions RC Colmar... -
Page 2: Table Of Contents
FRANCO BELGE, which has been granted the ISO 9001 certification, guarantees the quality of its appliances and is committed to meet its customers’ needs. FRANCO BELGE, which can boast a 75-year experience in the industry of heating devices, uses state-of-the-art technologies to design and manufacture its whole range of products. -
Page 3: Description Of The Unit
“Le Beffroi” ref. 174 10 54 Description of the unit This appliance is an oil-fired stove. WARNING An incorrectly installed oil-fired stove can cause serious accidents. This appliance should only be installed by competent personnel. 1. Description of the unit 1.1. -
Page 4: Operating Principle
“Le Beffroi” ref. 174 10 54 Description of the unit 1 - Air holes 4 - Automatic ignition (optional) 2 - Catalyser A - Control knob E - Oil level regulator 5 - De-scaling lever 2a : Upper ring B - Safety lever. F - Thermostat control 2b : Catalyser top C - Main float... -
Page 5: Installation Instructions
“Le Beffroi” ref. 174 10 54 Installation instructions 2. Installation instructions SAFETY NOTICE : Read carefully all instructions before starting the installation. If the stove is not 200 mm properly installed, a house fire may result. For your safety, follow the installation directions. Contact local building or fire officials about restrictions and installation inspection in your area. -
Page 6: Chimney Connector
“Le Beffroi” ref. 174 10 54 Installation instructions 2.4. Chimney connector The appliance must be as close as possible to the chimney. Avoid horizontal flue connection pipes which can dangerously restrain functioning of the appliance. The connector pipe must be either 24 ga. black painted or blued steel or 316 grade 20 ga. -
Page 7: Levelling
“Le Beffroi” ref. 174 10 54 Installation instructions 1 - Enamel top plate 2 - Natural stone 3 - Ceramic rope Figure 9 - Top panel assembly Fig. 10- Levelling 2.10. Oil flow adjustment The float regulator has been adjusted at the factory and should not need further adjustment. -
Page 8: Chimney Draught
“Le Beffroi” ref. 174 10 54 Installation instructions Please note - Very important : The adjustments of the float regulator are very sensitive. The hight and the low setting screws must never be turned more than a 1/4 of a turn at a time in any direction from their initial setting. When making any adjustments, allow 3 to 5 minutes between adjustments to allow burner to stabilize to previous adjustment before proceeding, if necessary. -
Page 9: Operating Instructions
“Le Beffroi” ref. 174 10 54 Operating instructions 3. Operating instructions 3.1. Fuel Warning : Your stove is fitted with a specific float regulator for a specific oil. • Fuel oil # 2 or fuel oil # 1 The fuel oil must be free from any dirt and water which could disturb the stove in operation. -
Page 10: Recommendation
“Le Beffroi” ref. 174 10 54 Operating instructions Using a soft bristle brush (a small clean paint brush), replace the filter in the regulator, install the cover plate carefully brush off the catalyser. Loosen any carbon and secure with the screw. soot from the bottom of the burner with a putty knife, •... -
Page 11: Trouble Shooting
“Le Beffroi” ref. 174 10 54 Operating instructions 3.7. Trouble shooting þ : This sign means that you should asked for a qualified engineer to do the work. SYMPTOM PROBLEM TEST SOLUTION Flames extinguish during Very cold chimney. No draft Leave door ajar until fire has caught. -
Page 12: Spare Parts
“Le Beffroi” ref. 174 10 54 Spare parts 4. Spare parts When ordering spare parts, specify the stove type and Example serial number, including the colour index (on the Stove “Le Beffroi”, guarantee or identification plate), the name of the part Ref. - Page 13 “Le Beffroi” ref. 174 10 54 Spare parts 6 9 / 7 0 7 0 / 6 9 Technical manual “954”...
- Page 14 § Guarantee certificate § § Legal guarantee of parts covered by the guarantee is found to be too costly vis-à-vis the price of the appliance, the decision to replace The specifications, dimensions and information shown on or repair the appliance will be taken by the vendor. our documents are provided for information purposes only Our guarantee is for 2 (two) years for all appliances, with and under no circumstances are binding upon the vendor.
