Belfort
Document n° 1002-3 ~ 17/05/2001
Français
English
Gas stove - EN 613.
Model : 154 05 08
Natural gas (type G20)
Category I
2H (GB).
Technical manual
to be saved
by the user
for future reference
Description of the appliance
Installation instructions
Operating instructions
Les Fonderies Franco-Belges
Spare parts
59660 MERVILLE
Phone : 03.28.43.43.43
Fax : 03.28.43.43.99
Warranty certificate
RC Hazebrouck 445750565B
Subject to modifications
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FRANCO BELGE Belfort 154 05 08
Summary of Contents for FRANCO BELGE Belfort 154 05 08
- Page 1 Belfort Document n° 1002-3 ~ 17/05/2001 Français English Gas stove - EN 613. Model : 154 05 08 Natural gas (type G20) Category I 2H (GB). Technical manual to be saved by the user for future reference Description of the appliance Installation instructions Operating instructions Les Fonderies Franco-Belges...
-
Page 2: Table Of Contents
FRANCO BELGE, which has been granted the ISO 9001 certification, guarantees the quality of its appliances and is committed to meet its customers’ needs. FRANCO BELGE, which can boast a 75-year experience in the industry of heating devices, uses state-of-the-art technologies to design and manufacture its whole range of products. -
Page 3: Product Information
Model 154 05 08 Product information Belfort WARNING The appliance must be installed in compliance with Current Building Regulations. Incorrectly installed, this appliance can be dangerous and possibly cause serious accidents. The manufacturer’s responsibility shall be limited to the supply of the equipment. 1. -
Page 4: Installation Instructions
Belfort Installation instructions Model 154 05 08 2. Installation instructions • • These instructions have been compiled in accordance Ensure that the stove corresponds to the type of gas it with EN 613 1995. is to be used with. This can be confirmed by checking the data badge located on the rear face of the •... -
Page 5: Flue Connection
Model 154 05 08 Installation instructions Belfort • The hearth must protrude at least 150 mm in front of the stove and 150 mm each side. • The hearth must not be capable of inadvertent covering by a carpet or rug. This should be achieved by either : the hearth being 50 mm above the level of the room floor. -
Page 6: Pressure Testing
(e.g. Corgi registered). Please ensure that when fitting the matrix and coals, that you DO NOT OBSTRUCT THE PILOT FRANCO BELGE accept no responsibility for any injury sustained whilst handling hot ceramics. Instructions for the layout of the prefixed ceramic matrix and loose coals for Belfort fitted with gas burner unit. -
Page 7: Test For Spillage
Model 154 05 08 Installation instructions Belfort 2.8. Service section 2.8.1. Troubleshooting chart Piezo-electric igniter : T h e s p a r k b e t w e e n t h e electrode and the head of the pilot light is not clean ;... -
Page 8: User Instructions
With control knob at ‘PILOT’ setting, depress and turn DO NOT OBSTRUCT THE PILOT in an anti clockwise, direction between the ‘LOW‘ FRANCO BELGE accept no responsibility for any injury setting and the high setting. sustained whilst handling hot ceramics. -
Page 9: Extinguishing The Stove Fully
Model 154 05 08 User instructions Belfort with the presence of water or absence of mains supply. 3.4.4. Extinguishing the stove fully The Belfort has a Piezo ignition which requires no external power source. The piezo works on the same From any heat setting or the permanent pilot, depress principle as a cigarette lighter, providing a spark when control knob fully and turn clockwise to ‘OFF’... -
Page 10: List Of Components
Belfort List of components Model 154 05 08 4. List of components * Colour index When ordering spare parts, specify the stove type and serial number, including the colour index, the name of A : 1540508Y = *EF the part and the part number, including the colour index. B : 1540508J = *79 Example : “Belfort"... - Page 11 Model 154 05 08 Belfort Figure 9 - Stove - Exploded view Technical manual...
- Page 12 Belfort List of components Model 154 05 08 327902 MJ Tray ..........C ....327902 MK Tray .
- Page 13 Model 154 05 08 Belfort Notes Technical manual...
- Page 14 - All installation and adjustment instructions listed in the FRANCO BELGE. Name and address of the installer : _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _...
