Metra Electronics 99-3309B-LC Installation Instructions Manual

Chevrolet Spark 2013-2015
KIT FEATURES
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Painted matte black to match the factory dash
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8" Phillips screws
• E) (10) White plastic panel clips • F) Axxess Interface included (not shown)
B
A
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • Axxess Interface included
Antenna Adapter: • 40-EU55
METRA. The World's best kits.
Installation instructions for part 99-3309B-LC
99-3309B-LC
C D
™
E
metraonline.com
Table of Contents
Dash Disassembly ..................................................2
Kit Preparation ....................................................... 2
Kit Assembly
– ISO DIN radio provision with pocket ...................... 3
–
ISO DDIN radio provision ...................................... 3
Axxess Interface Installation ................................ 4
– Connections to be made ....................................... 4
– Installing the Axxess interface .............................. 5
– Initializing the Axxess interface ............................ 5
– Vehicle customization with the optional AX-LCD ... 5
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
© COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
