Metra Electronics 99-3043 Installation Instructions

Chevrolet/gmc/isuzu/oldsmobile 1994-1997

Download this manual

INSTALLATION INSTRUCTIONS FOR PART 99-3043

Chevrolet/GMC/Isuzu/Oldsmobile 1994-1997

KIT FEATURES

• DIN and ISO DIN unit provisions

• Factory pocket provisions

KIT COMPONENTS

• A) Radio housing • B) Faceplate• C) Shaft supports • D) (4) 5 mm Flat head screws

• E) (2) Carriage bolts • F) (2) Keps nuts • G) (2) #6 Self tapping screws • H) ISO DIN brackets

METRA. The World's best kits.

APPLICATIONS

See application list inside

99-3043

™

1-800-221-0932

WIRING & ANTENNA CONNECTIONS (sold separately)

Wiring Harness:

• 70-1858 - GM harness for select 1988-2002

Antenna Adapter:

• 40-GM10 - GM adaptor for select 1988-2006

TOOLS REQUIRED

• Cutting tool • Phillips screwdriver • Socket wrench

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

metraonline.com

Need help?

Do you have a question about the 99-3043 and is the answer not in the manual?

Page 1 INSTALLATION INSTRUCTIONS FOR PART 99-3043 APPLICATIONS See application list inside WIRING & ANTENNA CONNECTIONS (sold separately) Chevrolet/GMC/Isuzu/Oldsmobile 1994-1997 Wiring Harness: 99-3043 • 70-1858 - GM harness for select 1988-2002 Antenna Adapter: KIT FEATURES • 40-GM10 - GM adaptor for select 1988-2006 •...
Page 2 99-3043 Dash Disassembly Applications All Vehicles Chevrolet 1. Remove (2) screws above the wiring, and remove the bezel. side tabs on the radio housing Blazer ..............1995-1997 speedometer cluster. (Figure A) between the mounting tabs on 5. Remove (4) screws securing S-10 Pickup ............
Page 3 Kit Assembly DIN head units provision 4. Mount the head unit/kit assembly ISO DIN head unit provision housing legs with (2) #6 self-tapping screws “B”. (Figure A) to the sub-dash with (4) screws 1. Snap the faceplate into the radio 1.
Page 4 INSTALLATION INSTRUCTIONS FOR PART 99-3043 NOWLEDGE IS OWER Enhance your installation and fabrication skills by enrolling in the most recognized and respected mobile electronics school in our industry. Log onto www.installerinstitute.com or call 800-354-6782 for more information and take steps toward a better tomorrow.
