Applications
The Loop-control CPU Unit Provides You with Solutions for the Complex and Advanced
Functions Demanded by Control Devices in an Increasingly Diverse Range of Equipment.
Sterilization and Disinfection of
Pharmaceuticals, Food and Beverages
NS-series PT
Control outputs
Pressure
Gradient Temperature Control for Planar
Temperature Control Across Multiple Points
Note: CJ1G-CPU45P-GTC only.
Gradient temperature control equalizes the temperatures at
multiple points, providing high-quality heat processing,
reducing energy loss until temperatures stabilize, and saving
labor in adjustments due to interference between heaters.
For details, refer to the SYSMAC CS/CJ Series Controllers for Gradient
Temperature Control Catalog (R141).
Providing Solutions to Other Problems
Electrical parts equipment
requiring high-speed
temperature control for
higher precision and
improved tact time.
6
Logging Trend Data
(monitoring and operation
windows)
Loop-control CPU Unit
Program pattern
control
Control outputs
Temperature
SCR
Thyristor
Diffusion furnaces that
perform cascade control
of heater temperatures
and internal chamber
temperatures.
Industrial Furnace
NS-series PT
Workpiece
Conveyor
Example: Planar Temperature Control of Multi-stage Furnaces,
Wafer and Glass Surface Temperatures, and Other Applications.
Average
temperature
controlled.
Food machines, semi- Fermentation equipment
conductor devices and requiring temperature,
other machines requiring pressure, flowrate, and pH
multipoint temperature control.
control.
Monitoring and operation
windows or heaters and
temperature sensors
Loop-control CPU Unit
Heater
Temperature
sensor
CPU: CJ1G-CPU45P-GTC
Gradient temperature
control
Interference at other
control output points
suppressed.
Testing devices
frequently change
setting conditions and
program settings.
Cascade control of
tunnel furnace
N atmosphere
2
Solder
Temperature
differences
controlled.
