List of Function Blocks
Type Block Name
Signal Selec- Rank Selector
tion/Switching (See note 1.)
Input Selector
(See note 1.)
3-input Selector
(See note 1.)
3-output Selector
(See note 1.)
Constant Selector
(See note 1.)
Constant Generator
(See note 1.)
Ramped Switch
Bank Selector
Split Converter
Constant Constant ITEM Setting
ITEM Setting (See note 1.)
Variable ITEM Setting
(See note 1.)
Batch Data Collector
(See note 1.)
Pulse Train Accumulated Value In-
Operation put Adder
Accumulated Value Ana-
log Multiplier
Accumulator for accu-
mulated value input
Contact input/Accumu-
lated value output
Accumulated Value In-
put/Contact Output
Others Analog/Pulse Width
Converter (See note 1.)
Sequence Contact Distributor
Operation
Constant Comparator
(See note 1.)
Variable Comparator
(See note 1.)
Timer (See note 1.)
ON/OFF Timer
(See note 1.)
Clock Pulse
(See note 1.)
Counter (See note 1.)
Internal Switch
(See note 1.)
Level Check
(See note 1.)
Contact Type ON/OFF Valve Manipu-
Control Target lator
Motor Manipulator
Reversible Motor Manip-
ulator
Motor Opening Manipu-
lator
Switch Meter
(See note 2.)
Note: 1. The Function Blocks dealing with high-speed operation
(operation cycle: 0.01, 0.02, and 0.05 seconds is possible).
2. Cannot be used with the CJ1G-CPU45P-GTC.
Function
Selects the rank of up to 8 analog signals.
Selects the specified analog signals specified by
the contact signal from up to 8 analog signals.
Selects and outputs one of three analog input
signals.
Outputs one analog input signal in three switched
directions.
Selects 8 preset constants by the contact signal.
Outputs 8 independent constants.
Switches two analog inputs (or constants) with a
ramp.
Records the PID parameters (SP, P, I, D, MH, ML)
in up to 8 sets in advance, and switches the PID
parameter for Basic/Advanced/Blended PID
Blocks according to the analog input range
(zone) or input bits.
Inputs the MV from the Basic PID block or Ad-
vanced PID block, converts the MV into two
analog outputs for V characteristics or parallel
characteristics (e.g., MV for heating or cooling)
and outputs them.
Writes the constant to the specified ITEM at the
rising edge of the send command contact.
Writes the analog signal to the specified ITEM at
the rising edge of the send command contact.
Stores each of max. 8 analog inputs to buffer by
a certain timing within sequential processing.
Adds up to four accumulated value signals.
Multiplies analog signals by the accumulated
value signals.
Converts 4-digit accumulated value signals to 8
digits.
Counts low-speed contact pulses, and outputs
8-digit accumulated signals.
Converts 4-digit accumulated value signals to
low-speed contact pulses before they are output.
Changes the ON/OFF duration ratio in a constant
cycle duration so that it is proportional to the
analog signal.
Connect contact signals between function blocks
in a 1:1 connection.
Compares up to eight sets of analog signals and
constants, and outputs the comparison results as
contacts.
Compares up to eight pairs of analog signals,
and outputs the comparison results as contacts.
2-stage output type addition timer for forecast
values and reached values. Can also output the
present value.
Timer for performing ON-OFF operation at preset
ON and OFF times.
Outputs a clock pulse at the setting time interval
for a single operation cycle.
2-stage output type addition timer for forecast
values and arrival values. Can also output the
current value.
Temporary storage contact for accepting relays in
the Step Ladder Program block.
Note: (One internal switch is already allocated
as "temporary storage" in CX-Process
Tool.)
Checks an analog input for 8 levels and outputs
a contact corresponding to the level. The level
number is also output as an analog value at the
same time.
Manipulates and monitors ON/OFF valves with
open/close limit switches.
Manipulates and monitors motor operation.
Manipulates and monitors reversible motor
operation.
Inputs a target opening, and manipulates an
electric positional-proportional motor.
Manipulates and monitors multiple (up to 8)
devices such as ON/OFF valves, motors, or
pumps.

Sequence Control

Type Block Name
--- Step Ladder Pro-
gram (See note.)
Note: The Function Blocks dealing with high-speed operation (oper-
ation cycle: 0.01, 0.02, and 0.05 seconds is possible).

Field Terminals

Type Block Name
Contact DI 8-point Terminal
I/O
DI 16-point Terminal Inputs 16 contacts from 16-point Input
(See note.)
DI 32-point Terminal Inputs 32 contacts from 32-point Input
DI 64-point Terminal Inputs 64 contacts from 64-point Input
DO 8-point Terminal Outputs 8 contacts from 8-point Output
DO 16-point Termi-
nal
DO 32-point Termi-
nal
DO 64-point Termi-
nal
DI 16-point/Do
16-point Terminal
Analog I/O AI 4-point Terminal
(See note.) (PTS51)
AI 4-point Terminal
(PTS52)
AI 2-point Terminal
(PTS15/16, PDC15)
AI 8-point Terminal
(AD081)
AO 8-point Terminal
(DA08V/C)
AI 4-point Terminal
(AD041)
AO 4-point Terminal
(DA041)
AO 2-point Terminal
(DA021)
AI 4-point/AO 2-point
Terminal (MAD42)
AI 4-point Terminal
(DRT1-AD04)
AO 2-point Terminal
(DRT1-DA02)
AI 4-point Terminal
(AD04U)
AI 4-point Terminal
(PH41U)
Note: The Function Blocks dealing with high-speed operation
(operation cycle: 0.01, 0.02, and 0.05 seconds is possible).
Function
Performs logic sequence and step pro-
gression control.
Function
Inputs 8 contacts from 8-point Input Unit.
Unit.
Unit.
Unit.
Unit.
Outputs 16 contacts from 16-point Output
Unit.
Outputs 32 contacts from 32-point Output
Unit.
Outputs 64 contacts from 64-point Output
Unit.
Inputs and outputs 16 contacts each from
16-point Input/16-point Output Units.
Inputs 4 analog signals from CJ1W-
PTS51 (Isolated-type Thermocouple
Input Unit)
Inputs 4 analog signals from CJ1W-
PTS52 (Isolated-type Temperature Resis-
tance Input Unit).
Inputs 2 analog signals from CJ1W-
PTS15 (Isolated-type Thermocouple
Input Unit), CJ1W-PTS16 (Isolated-type
Temperature Resistance Input Unit), or
CJ1W-PDC15 (Isolated-type DC Input
Unit).
Inputs 8 analog signals from the CJ1W-
AD081(-V1).
Outputs 8 analog signals from the CJ1W-
DA08V/DA08C.
Inputs 4 analog signals from the CJ1W-
AD041(-V1).
Outputs 4 analog signals from the CJ1W-
DA041(-V1).
Outputs 4 analog signals from the CJ1W-
DA021.
Inputs 4 analog signals and outputs 2 an-
alog signals each from the CJ1W-MAD42.
Inputs 4 analog signals from a DRT1-
AD04 DeviceNet Slave Analog Input Unit.
Outputs two analog signals from a DRT1-
DA02 DeviceNet Slave Analog Output
Unit.
Inputs 4 analog signals from the CJ1W-
AD04U.
Inputs 4 analog signals from the CJ1W-
PH41U.
