PD8I - Power Distribution Module
1A - 8A
1B - 8B
Fig. 1 ALTV248HI • ALTV248CBHI
Power
Switch
115VAC input
CCTV Isolated Series
Terminal Identification:
Phase 1
Phase 2
XFMR*
115VAC input
50/60 Hz
50/60 Hz
Used on PTC Models
(example: ALTV248CBI)
- 3 -
