Altronix ALTV248HI Installation Manual page 4

Fig. 2 ALTV248MI • ALTV248CBMI
1A
1B
F1
- 4 -
2A 3A 4A 5A
2B 3B 4B 5B
F2 F3 F4 F5 F6
Transformer
underneath
power supply
board
Power
Switch
6A 7A 8A
6B 7B 8B
F7 F8
Used on PTC Models
(example: ALTV248CBMI)
1A 2A 3A 4A
1B 2B 3B 4B
F1 F2 F3 F4 F5
5A 6A 7A 8A
5B 6B 7B 8B
F6 F7 F8
CCTV Isolated Series
