Inspection & Unpacking - Groen OM-TDB/7 Operator's Manual

The unit will arrive in a heavy shipping carton and will
be attached to a skid. Immediately upon receipt,
inspect the carton carefully for exterior damage.
CAUTION
SHIPPING STRAPS ARE UNDER TENSION
AND CAN SNAP BACK WHEN CUT. TAKE
CARE TO AVOID PERSONAL INJURY OR
DAMAGE TO THE UNIT BY STAPLES LEFT
IN THE WALLS OF THE CARTON.
Carefully cut the polyester straps around the carton
and detach the sides of the box from the skid. Pull
the carton up off the unit.
Thoroughly inspect the unit for concealed damage.
Report any shipping damage or incorrect shipments
to the delivery agent.
Inspection & Unpacking
The TDB/7 is shipped from the factory strapped on a
pallet. The tilt handle is inside the kettle.
Write down the model number, serial number, and
installation date, and retain this information for future
reference. Space for these entries is provided at the
top of the Service Log at the back of this manual.
Keep this manual on file and available for operators
to use.
CAUTION
T HIS UNIT WEIGHS 140 TO 163 LB. (64 TO
74 KG). INSTALLER SHOULD
HELP AS NEEDED TO LIFT T HIS WEIGHT
SAFELY.
When installation is to begin, carefully cut the straps
which hold the unit on the skid. Lift the unit straight up
off the skid. Examine packing materials to be sure
loose parts are not discarded with the materials.
Attach the tilt handle (normally shipped inside the
kettle) by carefully threading it into the socket on the
trunnion support. Be careful to avoid cross-threading
fine socket threads.
7
OM-TDB/7
OBTAIN
