Identifying the Camera on your Network

6.1 Identifying the Camera IP Address

To begin viewing video or configuring a camera's network settings from the camera's web/browser
interface, the user must first identify the device's IP address. The default IP address of the camera is
192.168.XXX.XXX. The default subnet mask is 255.255.0.0.
On simple, private networks, a user can manually identify the IP address of the camera by converting the
camera's MAC address hex values, however, the alternative method, which is recommended by 3xLOGIC,
is to use the 3xLOGIC (VSX-IP) Camera Setup Utility. The utility makes detection and configuration of VISIX
camera's in any network environment simple and easy, regardless of network complexity.
Please install the camera before continuing. Neither of the below methods require an external internet
connection, however, the camera and the PC being used to communicate with it must reside on the same
network.
6.1.1

MANUALLY IDENTIFY CAMERA IP ADDRESS (MAC ADDRESS HEX CONVERSION)

Users can access the camera's web interface and settings using a device's default IP address: In case of
generic private network environment where IP address 192.168.XXX.XXX are used, the following procedure
can be used to identify a device's IP address.
Steps:
1. Convert the device's MAC address to the IP address. Refer to Section 10:
Conversion Chart
bottom of the device).
MAC address = 00-13-23-01-14-B1 → IP address = 192.168.20.177
Convert the last two sets of hexadecimal numbers to decimal numbers.
2. Start the Microsoft® Internet Explorer web browser and enter the address of the device.
3. Web streaming and device configurations are supported through ActiveX program. When the
ActiveX installation window appears, authorize and install the ActiveX.
6.1.2 AUTOMATICALLY IDENTIFY CAMERA IP ADDRESS WITH 3XLOGIC CAMERA
SETUP UTILITY
Using the 3xLOGIC Camera (VSX-IP) Setup Utility is recommended for any network environment as it will
find all VISIX cameras across multiple subnet masks, utilizing mDNS search discovery. Camera
information such as IP Address, Subnet Mask and Gateway Settings will be displayed and can be edited
from this utility. To search for a device, launch the utility (VSXIPUtility.exe).
NOTE: VSXIP Utility v9.40.0226 or newer is required for detection of the VX-VTOF-1.
Steps:
1. Click on Detect Online Devices/ Change IP Address to proceed to the Online Devices window.
10385 Westmoor Drive, Suite 210, Westminster, CO 80021 | www.3xlogic.com | (877) 3XLOGIC
User Manual | VISIX Time of Flight People Tracking Camera
(the MAC address of the device is written on the label affixed to the side or
Hexadecimal-Decimal
