3xLogic VX-VTOF-01 User Manual page 17

Select the items among network settings, user account information and time zone setting to keep them
preserved from the initialization.
Click the Factory Default button. Then, the dialog box will appear to ask you if you want to reset all
settings.
Click the OK button, and wait until the 'Reset All Settings' page is refreshed after the reboot. Then, all the
parameters except for the unchecked items will be initialized.
NOTE: The factory default settings can be inferred as follows:
Factory Default Connection Settings
IP Address
Network Mask
Gateway
Username
Password
10385 Westmoor Drive, Suite 210, Westminster, CO 80021 | www.3xlogic.com | (877) 3XLOGIC
User Manual | VISIX Time of Flight People Tracking Camera
192.168.xx.yy
255.255.0.0
192.168.0.1
Admin
12345
