Summary of Contents for Rear view safety RVS-912619P
- Page 2 What’s in the Box? • COLOR WEATHERPROOF THIRD-BRAKE-LIGHT CAMERA • 7" TFT LCD DIGITAL CLIP-ON MIRROR MONITOR • 3 CHANNEL MULTIPLEXER CONTROL UNIT • 33’ CAMERA CABLE • REMOTE CONTROL • POWER CONNECTION WIRE • DOUBLE RCA + POWER CONVERTER (TO CONNECT EXTERNAL AUDIO, VIDEO AND POWER) •...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................4 Safety Information ..................5-7 Before Beginning Installation..............8 Installation Guide..................9 Wiring Camera & Monitor..............10-11 Installation Tips ...................12-13 Installation Diagram .................14 Installing the Monitor ................15 Monitor Operation ................... Splicing ......................17 Positioning....................Multiplexer ....................19 Monitor Dimensions..................20 Monitor Specifications ................21 Camera Dimensions...................22 Camera... -
Page 4: Introduction
TV viewer or screen located for- ward of the back of the driver’s seat or in any location that is vis- ible, directly or indirectly, to the driver while operating the vehicle. REAR VIEW SAFETY... -
Page 5: Safety Information
Safety Information Please read the entire manual and follow the instructions and warnings carefully. Failure to do so can cause serious damage and/or injury, including loss of life. Be sure to obey all applica- ble local traffic and motor vehicle regulations as it pertains to this product. - Page 6 Dropping the unit may cause is detected, disconnect the possible mechanical failure. system immediately. • Where the power cable may touch a metal case, cover the cable with a friction tape. A short circuit or disconnected wire may cause a fire. REAR VIEW SAFETY...
-
Page 7: Safety Information
Safety Information If you have questions about this product, contact: Customer Service: Rear View Safety 1797 Atlantic Avenue Brooklyn, NY 11233 Tel: 1.800.764.1028 IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT. -
Page 8: Before Beginning Installation
Install split grommets where applicable. Step 3: Once all cables and wiring have been properly routed, perform a system function test by temporarily connecting the system. If the system seems to not be operating properly see troubleshooting (page 22). REAR VIEW SAFETY... -
Page 9: Installation Guide
Installation Guide Camera 1. Attach camera bracket close to rear marker lights, centered on vehicle. 2. Attach camera to bracket using screws provided and adjust the angle. Cable 1. Be sure to position the cable properly. The aviation camera cable uses aircraft grade connectors which means the camera cable can be exposed to all weather elements, do not run the cable over sharp edges, do not kink the cable and keep away from HOT and rotating parts. -
Page 10: Wiring Camera & Monitor
Camera: Drill a 20mm (0.8in) drain battery. Therefore it is diameter hole into vehicle recommended to connect body near the camera and power to an ignition switched bracket. Insert camera cable into accessory power source. vehicle (be careful not to kink REAR VIEW SAFETY... -
Page 11: Wiring Camera & Monitor
Wiring Camera & Monitor • Audio works on two ports of consumption is 10 to 30 Volts. multiplexer and positive triggers • When installing all THREE (3) must be triggered for audio to cameras, use all three ports and operate. These are port labeled connect all positive triggers to “backup”... -
Page 12: Installation Tips
B. If you are not using our monitor with multiplex box, you can open the hood of the Sprinter, take the cover off the fuse block and get the reverse trigger off the blue wire. REAR VIEW SAFETY... -
Page 13: Installation Tips
Installation Tips Reverse With Confidence ™... -
Page 14: Installation Diagram
Installation Diagram Figure 1.1 Figure 1.2 Figure 1.3 REAR VIEW SAFETY... -
Page 15: Installing The Monitor
Installing the Monitor 33ft Extension Cable Monitor Optional Video Out Camera Available -3 Amp Fuse 1. DC12V-24V (red) 2. Ground (black) 3. Port #3 (blue) 4. Port #2 (white) 5. Port #1 (yellow) Camera Reverse With Confidence ™... -
Page 16: Monitor Operation
To reset your system, press “MENU” 11 times and use arrows • To view images on other cameras, press “CAMERA SELECTION” 1 time for camera one, 2 times for camera two and 3 times for camera three. REAR VIEW SAFETY... -
Page 17: Splicing
Splicing 1. Red - Power (+) 2. Yellow - Video 3. Green - Mirror / Normal Imaging 4. White - Audio 5. Black - Ground (-) Reverse With Confidence ™... -
Page 18: Positioning
Positioning REAR VIEW SAFETY... -
Page 19: Multiplexer
Multiplexer Port #1 Port #2 Port #3 or DVD Backup Reverse With Confidence ™... -
Page 20: Monitor Dimensions
Monitor Dimensions REAR VIEW SAFETY... -
Page 21: Monitor Specifications
Monitor Specifications TFT LCD Digital Monitor Screen Size Digital 7” Dot Resolution x 3 (RGB) x 480 Display Format 16:9 Display Brightness 400cd/m Viewing Angle 90° min Video Input 3 channel Video Source 1Vp-p, 75 Power Supply DC 12V-24V (+/-10%) Power Consumption Operating Temperature -10°C - +65°... -
Page 22: Camera Dimensions
Camera Dimensions REAR VIEW SAFETY... -
Page 23: Camera Specifications
Camera Specifications Camera MT9V136 Picture Elements 250,000 pixels Gamma Correction r=0.45 to 1.0 Image Sensor 480TV lines PAL:500 / NTSC:510 x 492 Lens 2.1mm View Angle 130° Sync System Internal Synchronization Night Vision Usable Illumination 0.3 Lux Power Source DC 12V-24V (+/-10%) S/N Ratio More than 48dB Electronic Iris... -
Page 24: Troubleshooting
Verify Blue trigger is receiving monitor power • Verify camera is connected to cable Audio on Camera Verify chosen camera has audio Confirm that the Blue audio • • Verify volume setting trigger is connected to 12v+ • REAR VIEW SAFETY... -
Page 25: Warranty
Warranty One Year Warranty RVS Systems Inc. warrants this product against material defects for a period of one year from date of purchase. We reserve the right to re- pair or replace any such defective unit at our sole discretion. RVS Systems Inc. -
Page 26: Disclaimer
Neither shall RVS Systems and/or its affiliates have any responsibility for any decision, action or inaction taken by any person in reliance on RVS Systems systems, or for any delays, inaccuracies and/or errors in connection with our systems functions. REAR VIEW SAFETY... - Page 27 Take Notes ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ ________________________________________ Reverse With Confidence ™...
- Page 28 If you have any questions about this product, contact: Rear View Safety, Inc. 1797 Atlantic Avenue Brooklyn, NY 11233 800.764.1028 BETTER CAMERAS. BETTER SERVICE. IT’S OUR GUARANTEE.
