Important Safety Information Please keep this manual in a safe place for easy reference. 1. It is important to read this entire manual before assembling and using the equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained and used properly.
Parts List Product name Specification Quantity Main frame assembly Rear frame assembly Handle upright Backboard frame assembly Handle Bar Magnetic board assembly Rear leg assembly Front leg assembly Armrest assembly Square neck bolt Arc gasket Cap nut Rear leg end cap Front leg end cap Length 850(15a、15b)...
Page 5
Grip splicing socket, plug Cross pan head self tapping bolt Square pipe plug Elastic bolt Cone nut Cambered gasket Inner hexagon cheese-head bolt Spring gasket Handlebar grip Round pipe plug welded pipe Clip cover shift tuning knob assembly Cambered gasket Cross pan head self tapping bolt Electronic meter Gasket...
Page 6
PVC,9 grids,28×84 Magnetic block positioning grid Square magnet Magnetic board shaft Shaft closing ring Gasket Elastic gasket full teeth Hexagon bolt Inertia wheel Inertia wheel Bearing bolt Adjust Thin nut Flange nut Triangle belt Manufacturer: Sanwei 864 Belt pulley Crank left and right reverse teeth Bottom bracket cup Nine-piece type...
Page 7
Floor tube bush Length 650(79a、79b、79c) Inductive connection wire Jacketed line connecting bolt 1300, Micro adjusting connection wire with a thrum length of 42 Enclosed tools and spare parts list Name Model Quantity Thumbnail Square neck bolt Cambered gasket Cap-shaped nut Elastic bolt Square neck bolt...
Page 8
Assembly Instructions Step 1: Connect the rear leg assembly (8) to the main frame (1) with 2-square neck bolts (10), cambered gaskets (11) and high cap-shaped nuts (12). Step 2: Connect the rear leg assembly (7) to the rear frame (2) with 2-square neck bolts (10), cambered gaskets (11) and high cap-shaped nuts (12).
Page 9
Step 4: The backboard frame assembly (4) is connected to the rear frame assembly (2) by 4-inner hexagon pan head bolts (16). The seat cushion (18) and the back cushion (19) are attached to the backboard frame respectively by 4-inner hexagon pan head bolts (16) and the gaskets (17) as shown Step 5: The armrest assembly (9) is attached to the backboard assembly (4) by 2-square neck...
Step 7: Attach handlebar (5) to handle upright (3) with 2-inner hexagon cheese head bolts (31) and spring gaskets (32). Snap clip cover (35) over top to protect head bolts. Step 8: Attach the shift tuning knob assembly (36) with the truck line (80) as shown in the sub-figure (1), (2) and (3).
