POWER-STEPPER
OWNER'S MANUAL OBS 2233B
Exercise of strenuous nature, as is customarily done on this equipment, should
not be undertaken without first consulting a physician. No specific health
claims are made or implied as they relate to the equipment. Measurements
made by the equipment are believed to be accurate, but only the
measurements of your physician should be relied upon.
IMPORTANT: Read all instructions carefully before using this product. Retain
this product. Owner's manual for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Orbit OBS 2233B

Summary of Contents for Orbit OBS 2233B

  • Page 1 POWER-STEPPER OWNER’S MANUAL OBS 2233B Exercise of strenuous nature, as is customarily done on this equipment, should not be undertaken without first consulting a physician. No specific health claims are made or implied as they relate to the equipment. Measurements made by the equipment are believed to be accurate, but only the measurements of your physician should be relied upon.

  • Page 2: Table Of Contents

    Contents Implied warranty Safety instructions Hardware pack Explosion diagram Part List Assemble instructions Functions and Features Maintenance Training Organization...

  • Page 3: Implied Warranty

    Dear customers We want to thank you for having chosen my POWER-STTEPPER and wish you a lot of fun and success during training. Please note and follow the enclosed safety and assembly instructions carefully. If you have any questions please do not hesitate to contact us. Implied Warranty Prerequisite for the implied warranty is the proper setup in accordance with the operating instructions.

  • Page 4: Safety Instructions

    Safety instructions This product has plentiful design and fabrication in terms of safe use. However, the operator shall still follow the instructions below in operation to provide against emergencies. We will not be responsible for any consequences arising from abnormal operations.
  • Page 5 The stepper is suitable for your cardio-pulmonary function, and temper your muscle  for your leg and haunch. But it is not suitable for therapeutic purposes.  Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout the EU.

  • Page 6: Hardware Pack

    HARDWARE PACK...
  • Page 7 Description 22/24 PEDAL TUBE AND FRONT STABILIZER WELDING UNDER FRAME 51/53 UPPER FRAME AND SENSOR WIRE 4/6/7 REAR STABILIZER AND TRANSPORTATION WHEELS 36/39 HANDLEBAR HYDRAULIC CYLINDER FOOT PEDAL 1 SET WATER BOTTLE FRAME MONITOR 12 SIDE END CAP STOPPER BALL KNOB BIG CROSS HEAD MACHINE SCREW (M5*16) 10/11/50 CROSS HEAD MACHINE SCREW M6*40 + FLATE...

  • Page 8: Explosion Diagram

    Explosion diagram Most of the displayed parts in this diagram are shipped pre-assembled. For spare parts, please do always specify parts numbers used on this diagram or in the following parts list.

  • Page 9: Part List

    Parts List DESCRIPTION DESCRIPTION Q’TY NO Q’TY UNDER FRAME NY LON NUT (M10) ACORN NUT (M10) FLAT WASHER (10) CURVE WASHER (10) HEX BOLT (M10*95) REAR STABILIZER BALL KNOB 12 SIDE END CAP CABLE PROTECTOR BIG CROSS HEAD MACHINE HEX BOLT (M8*20) SCREW (M5*12) TRANSPORTATION WHEELS GRIP...

  • Page 10: Assemble Instructions

    Assemble instructions Step 1 A) Attach two 12 side end cap (5) to rear stabilizer (4). Adjust the level of two end cap (5). B) Attach stopper (9) to rear stabilizer (4). C) Attach rear stabilizer (4) to under frame (1) with carriage bolt (8), curve washer (3), spring washer (48) and acorn nut (2).
  • Page 11 Step 3 A) Connect two sensor wires (27&53) together. See the drawing of (A). B) Attach upper frame (51) to under frame (1) with Allen bolt (52), flat washer (14), nylon nut (15) and plastic cap (46). Step 4 A) Attach two hydraulic cylinder (21) to upper frame (51) with hex bolt (33), big flat washer (18) and plastic cap (46).
  • Page 12 Step 5 A) Attach handle bar (36) to upper frame (51) with carriage bolt (42), curve washer (47) and acorn nut (49). B) Insert the computer to the top of the oval tube of upper frame (51). Connect up plug of sensor cable (27) to the socket of the computer (40).

  • Page 13: Functions And Features

    Functions and Features 1. SCAN: Press “mode” key to select “scan” mode w/a “scan” sign on the upper left comer of the upper left comer of the monitor. Then this function will automatically scans through, all the functions displayed on the bottom line of the monitor.

  • Page 14: Maintenance

    Maintenance How to folding How to move the device Lift the device to 45º so that the move wheels point downwards and to the front, and use the fixed handlebar to move it. How to maintain the device Inspect and tighten all parts of the device regularly. Replace any worn part immediately. For continued smooth operation of the device, the front and rear thwart pipes should be kept clean.

  • Page 15: Training Organization

    Training Organization Warm-up phase Before every training you should warm-up for 5~10 minutes. Here you can do some stretching and training with low resistance. Exercise phase During the actual training a rate of 70%~85% of the maximum pulse rate should be chosen.
