PRESETS PANEL (

The Preset panel allows to manage all the 10s available configurations.
For each configuration it is possible to set the name and all the parameters value except for
FACTORY and USER configurations (see table below).
PRESETS:
FACTORY
USER
OTHERS
√=change is allowed
* Be careful to write a meaningful name for the preset because the name will appear on the settings
list of the device menu! Please, avoid empty names.
If a parameter is "locked", it cannot be modified by device menu (using OLED display), while if "don't
care" propriety is active, when the user load the configuration, the parameter's value doesn't
changed.
ATTENTION: Changes are applied only after a "save" action.
NOTE: "a trick" In case of the user have a locked parameter and he is in great need for modify it, he
can save the configuration to USER configuration by OLED (see PRESET menu) and then load the
USER configuration (in this way all the parameters have the lock propriety disable and the user can
modify all the parameters).
FILE MENU
Save a .wcf file
With an infrared device correctly connected, select File->Save User Configuration and select the
destination file.
Load a .wcf file
To load a user configuration select File->Load User Configuration and select a previously saved data
file; a form will be shown, where it's possible to select which data has to be restored and which
skipped. This allow the user to load a particular configuration while keeping other data.
❹
)
NAME* LOCK/DON'T CARE
√
MTP40S User Manual
PARAMETERS
VALUE
√
Using a file menu at the top left of the
panel it is possible to load/save all the
configuration values of the device
to/from a .wcf file (Wisycom
Configuration File).
√
√
17
