MIC Mode setting (only for LEMO option):
MIC Mode:
Pin out
1=GND
'2 wires':
3=AF
1=GND
'2 wires + bias':
3=AF+5.5V
1=GND
'3 wires': 2=5.5V
3=AF
1=GND
'2 wires & 2=3.1V (power for
phantom': PHA48)
3=AF
1=GND
'2 wires + bias & 2=3. 1V (power for
phantom': PHA48)
3=AF+5,5V
3 PIN LEMO CONNECTOR
(use FVB.00.003.NLN on Mic)
Gain PTT
Disable
Normal
-60/40 dB
Muting
No data
Disable
Normal
-60/40 dB
Muting
No data
Disable
-60/40 dB
No data
Disable
-60/40 dB
No data
Disable
-60/40 dB
No data
MTP40S User Manual
Led Mode
None
Mod. Peak
PTT
None
Mod. peak
PTT
None
Mod. peak
None
Mod. peak
None
Mod. peak
