XC-14A, XC-22A, XC-30A SERVICE MANUAL
Electrical parts and relay board removal
<XC-22A, XC-30A>
TH1
TH2
TH3
Data cable connector
Xtreme Power Conversion® (XPC) Corporation
MC : Magnetic Contactor
Fan Motor
for Condenser
Capacitor
for Condenser Motor
Compressor
(R-C)
Portable Air Conditioners
Full Drain Switch
(Compressor)
(R)
Capacitor
for Compressor
MCCB: Mold case
Current Braker
OCR: Over Current Relay
Capacitor
for Evaporator Motor
(S)
(C)
