XC-14A, XC-22A, XC-30A SERVICE MANUAL
5. SET TEMP BUTTON
Change target temperature / data value by ± 1.
Change data value by ± 10 by pressing continually.
Press the SET TEMP BUTTONS to set temperature
Upper button is to heighten temperature and Lower
button is to lower temperature.
6. ALARM
Alarm indicator light blinks and indicates abnormal
system operation.
If Alarm occurs, compressor stops.
System operation stops when ALARM light is activated /
blinking longer than 3 minutes.
7. CURRENT TEMP
Room cool mode displays current room temperature
in display in Fahrenheit
SPOT / COOL Mode displays outlet (cool air) temperature
during normal operations.
In order to change °F to °C, press SPOT / COOL and
ROOM / COOL buttons together for 2 seconds.
C will blink 2 times and the figure will change to °C
ALARM codes blink and are displayed when abnormal
operation occurs.
8. TARGET TEMP
Displays the unit set temperature for ROOM COOL mode
only
NOTE:The room temperature display range is from 14 °F to 122 °F.
(When displayed in "°C " the range is from -10 °C to 50 °C)
