XC-14A, XC-22A, XC-30A SERVICE MANUAL
Back Cover Panel
Low Cover Panel
Xtreme Power Conversion® (XPC) Corporation
Screws (8)
Screws (4)
Screws (2)
Screws (8)
Right Side Panel
Portable Air Conditioners
10) Take out the eight (8) screws, and
then remove the back cover panel.
11) Take out the four (4) screws.
Unfasten two (2) screws to a half point
and then remove the low cover panel.
12) Take out the eight (8) screws, and
then remove the right-side panel.
Page 45
