Control Panel Removal - EXTRE COOLING XC-14A Service Manual

XC-14A, XC-22A, XC-30A SERVICE MANUAL
Control panel
Connector
Back Plate Panel
Air Filter
Page 44
6) Take out the fourteen (14) screws,
Screws (14)
Upper Panel
7) Unfasten the connector from the
8) Remove the air filter from the
9) Take out the two (2) screws, and
Screws (2)
Xtreme Power Conversion® (XPC) Corporation
Portable Air Conditioners
and then remove the upper panel.
control panel and then remove the
front panel.
back panel.
then remove the back plate panel.
