XC-14A, XC-22A, XC-30A SERVICE MANUAL
Evaporator Fan Motor
• The fan motor is a single phase, induction type.
The motor rotates the fan.
• The following table shows the specifications of
the fan motor used for each model.
NOTE:An internal overload relay is used to protect
the fan motor. This relay is built into the fan motor
and interrupts the flow of current when there is an
over current situation, or if abnormally high
temperature builds up in the fan motor.
Condenser Fan Motor
• The fan motor is a single phase, induction type.
The motor rotates the fan.
• The following table shows the specifications of
the fan motor used for each model.
NOTE:An internal overload relay is used to protect
the fan motor. This relay is built into the fan motor
and interrupts the flow of current when there is an
over current situation, or if abnormally high
temperature builds up in the fan motor.
