XC-14A, XC-22A, XC-30A SERVICE MANUAL
DISASSEMBLY (For XC-14A)
Disassembly
Cooling Air Duct
Page 36
Screws (4)
Drain Tank
Screws (3)
electric cover
Circuit Breaker
1) Remove the drain tank.
2) Take out the four (4) screws, and
then remove the cooling air duct.
3) Take out the three (3) screws, and
then remove the electric cover.
4) Off the circuit breaker.
(For safety)
Xtreme Power Conversion® (XPC) Corporation
Portable Air Conditioners
