XC-14A, XC-22A, XC-30A SERVICE MANUAL
Connector
Screws (5)
Xtreme Power Conversion® (XPC) Corporation
Screws (7)
Screws (2)
Front Panel
Control panel
Portable Air Conditioners
5) Take out the seven (7) screws.
Unfasten two (2) screws to a half point.
Pull the front panel forward.
6) Disconnect the connector from the
control panel and then remove the
front panel.
7) Take out the five (5) screws, and
then remove the upper panel.
Page 37
