Appendix C Information Command Returns

Driveinfo
Sled Capacity Errors TYPE
..
=== ====== ===== ===== =====
1 76292MB 0 JBOD 1
2 76292MB 0 JBOD 2
3 76292MB 0 JBOD 3
4 76292MB 0 JBOD 4
5 76292MB 0 JBOD 5
6 76292MB 0 JBOD 6
7 76292MB 0 JBOD 7
8 76292MB 0 JBOD 8
9 76292MB 0 JBOD 9
10 76292MB 0 JBOD 10
11 76292MB 0 JBOD 11
12 73307MB 0 JBOD 12
DriveInfo 7 2
JBOD VDID 19
Sled = 7, Drive = 2
Drive Model: Maxtor 98196H8
S/N: V80D15GC F/W Rev: ZAH814Y0 ATA Rev: 007e
Capacity: 76292 MB (09502790 blocks)
PIO: 03 MDMA: 07 UDMA: 07 QD: 00 CMDSet: 7c69 4309
Operations Blocks
Read 00000000 00000000
Write 00000000 00000000
Errors 00000000
DriveInfo RAID10 3
========= Drive 1 =========== ========= Drive 2 ==============
Sled Capacity Errors TYPE VDID Capacity Errors TYPE VDID
=== ====== ====== ===== ==== ======= ==== ====== ======
1 76292MB 0 RAID10 56
2 76292MB 0 RAID10 56
3 76292MB 0 RAID10 56
4 76292MB 0 RAID10 56
5 76292MB 0 RAID10 57
6 76292MB 0 RAID10 57
7 76292MB 0 RAID10 57
8 76292MB 0 RAID10 57
9 76292MB 0 RAID10 58
10 76292MB 0 RAID10 58
11 76292MB 0 RAID10 58
12 73307MB 0 RAID10 58
DriveInfo 7 2
RAID10 VDID 57 State: ONLINE
RAID10 Member Index 5 of total members 8 disks
RAID10 Interleave Size 128 Blocks
Sled = 7, Drive = 2
Drive Model: Maxtor 98196H8
S/N: V80D15GC F/W Rev: ZAH814Y0 ATA Rev: 007e
Capacity: 76292 MB (09502790 blocks)
PIO: 03 MDMA: 07 UDMA: 07 QD: 00 CMDSet: 7c69 4309
Operations Blocks
...
VDID Capacity Errors TYPE VDID
====== ===== =====
76292MB 0 JBOD 13
76292MB 0 JBOD 14
76292MB 0 JBOD 15
76292MB 0 JBOD 16
76292MB 0 JBOD 17
76292MB 0 JBOD 18
76292MB 0 JBOD 19
76292MB 0 JBOD 20
76292MB 0 JBOD 21
76292MB 0 JBOD 22
76292MB 0 JBOD 23
73307MB 0 JBOD 24
76292MB 0 RAID10 56
76292MB 0 RAID10 56
76292MB 0 RAID10 56
76292MB 0 RAID10 56
76292MB 0 RAID10 57
76292MB 0 RAID10 57
76292MB 0 RAID10 57
76292MB 0 RAID10 57
76292MB 0 RAID10 58
76292MB 0 RAID10 58
76292MB 0 RAID10 58
73307MB 0 RAID10 58
.
=====
A-iv
