Table of Contents
Please check and identify the supplied
For the United Kingdom only:
Use the numbers indicated in
parentheses when asking for
replacements parts.
"As of November 2012"
● AC adaptor
For Continental Europe: RFX0B43
For United Kingdom: (RFX0B44)
● 2 Nickel-metal hydride rechargeable
batteries (HHR-4AGE/2B)
● 4 Nickel-metal hydride rechargeable
batteries (HHR-4AGE/2B)
Information for Users on
Collection and Disposal of
Old Equipment and used
These symbols on the
products, packaging, and/or
accompanying documents
mean that used electrical and
electronic products and
batteries should not be mixed
with general household waste.
For proper treatment, recovery and
recycling of old products and used
batteries, please take them to applicable
collection points, in accordance with
your national legislation and the
Directives 2002/96/EC and 2006/66/EC.
By disposing of these products and
batteries correctly, you will help to
save valuable resources and prevent
any potential negative effects on
human health and the environment
which could otherwise arise from
inappropriate waste handling.
For more information about collection and
recycling of old products and batteries,
please contact your local municipality,
your waste disposal service or the point
of sale where you purchased the items.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
For business users in the
European Union
If you wish to discard
electrical and electronic
equipment, please
contact your dealer or supplier for
further information.
[Information on Disposal in other
Countries outside the European Union]
These symbols are only valid in
the European Union. If you wish to
discard these items, please contact
your local authorities or dealer and
ask for the correct method of disposal.
Note for the battery
symbol (bottom two
symbol examples):
This symbol might be
used in combination with
a chemical symbol. In this case it
complies with the requirement set
by the Directive for the chemical
Restriction of use
For use only in the countries listed on
page 6.
The radio frequencies this unit uses
(863 to 865 MHz) are not permitted in
some countries.
AC adaptor
Handle the AC adaptor carefully.
Improper handling is dangerous.
● Do not touch it with wet hands.
● Do not place heavy objects on top of it.
● Do not forcibly bend it.
Be sure to use the supplied AC adaptor.
● The rechargeable battery can be
recharged about 500 times. If its
operating time becomes extremely
short, you should replace it.
● Do not mix old and new batteries or
different types of batteries.
● Remove all the batteries if the set will
not be used for a long period of time.
● Carry and store the rechargeable
batteries in the battery carrying case
to prevent contact with metal objects.
● Do not heat or expose to fl ame.
● Do not leave the batteries in a car
exposed to direct sunlight for a
long period of time with doors and
windows closed.
● Do not peel off the covering on
batteries and do not use if the
covering has been peeled off.
Mishandling of batteries may cause
electrolyte leakage which may damage
items when the leaked fl uid comes into
If electrolyte leaks from the battery,
consult your dealer.
Wash thoroughly with water if
electrolyte comes in contact with any
part of your body.
● Keep the battery and 6.3 mm stereo
standard plug adaptor out of reach of
children to prevent swallowing.
The unit
No altering or remodeling
This may cause malfunctioning.
No dropping or strong impacts
This may damage the unit.
Avoid using the unit in the following
locations since they may cause
● Bathrooms and other moisture-prone
● Warehouses and other dusty places
● Very hot places near heating
appliances, etc.
Do not leave the unit exposed to direct
sunlight for long periods of time.
This may deform or discolor the
cabinet and may also cause

Power sources

See illustrations on page 3-
Recharge the batteries before using
the unit.
Insert the two rechargeable
batteries (supplied) into
the battery compartment in
the left housing (L) of the
● Correctly align the + and -
poles when inserting.
● Push toward - pole spring when
● Remove the + poles fi rst when
● Push the edge of [BATT]
compartment lid up to open. a
● Close [BATT] compartment lid
fi rmly after inserting the batteries.
Connect the supplied AC
adaptor to the transmitter, and
then to a household mains
c Household mains socket
(AC 230 V to 240 V, 50 Hz)
Turn off [OPR] switch and
place the headphones on the
Place the headphones on the
transmitter so that the charging
pins on the transmitter engage the
charging contacts on the bottom of
the left housing (L).
[OPR/CHG] indicator goes red and
charging starts.
The indicator goes out when the
batteries are fully charged.
● Approximate recharging and
operating time
Recharging: 24 hours
Operating: 20 hours
To check the remaining battery
Recharge the batteries when [OPR]
indicator on the left housing (L) starts
to fade and/or fl ash, or when sound
becomes distorted or fades.
Recharge the batteries in the
environment of ambient temperature
between 5 °C and 35 °C. In other
environments, charging time may
become longer, or charging may be
Service life of the batteries:
If [OPR] indicator on the left housing
(L) dims or fails to light even after
recharging the batteries, they have
come to the end of their serviceable life
and need to be replaced.
2 Nickel-metal hydride rechargeable
batteries (Part no.: HHR-4AGE/2B).
For your reference:
Dry cell batteries (R03/LR03, AAA)
can be also used to power the
Do not attempt to recharge them.
