KIEN1005G User's Manual 201106
KIEN1005G
Industrial Ethernet Switch
Hardware Installation Manual
Kyland Technology Co., LTD.
Publication Date: June 2011
Version: V1.0
Customer Service Hotline: (+8610) 88796676
FAX: (+8610) 88796678
Website: http://www.kyland.cn
E‐mail: support@kyland.biz
No.: 1.12.02.1027‐0
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for KYLAND Technology KIEN1005G
Summary of Contents for KYLAND Technology KIEN1005G
- Page 1 KIEN1005G User’s Manual 201106 KIEN1005G Industrial Ethernet Switch Hardware Installation Manual Kyland Technology Co., LTD. Publication Date: June 2011 Version: V1.0 Customer Service Hotline: (+8610) 88796676 FAX: (+8610) 88796678 Website: http://www.kyland.cn E‐mail: support@kyland.biz No.: 1.12.02.1027‐0 ...
- Page 2 KIEN1005G User’s Manual 201106 KIEN1005G Industrial Ethernet Switch Hardware Installation Manual Disclaimer: Kyland Technology Co., Ltd. tries to keep the content in this manual as accurate and as uptodate as possible. This document is not guaranteed to be errorfree, and we ...
- Page 3 KIEN1005G User’s Manual 201106 Notice for Safety Operation This product performs reliably as long as it is used according to the guidance. Artificial damage or destruction of the equipment should be avoided. Read this manual carefully and keep it for future reference; Do not place the equipment near water sources or damp areas; Do not place anything on power cable and put the cable in unreachable places; Do not tie or wrap the cable to prevent fire. Power connectors and other equipment connectors should be firmly interconnected and checked frequently. Do not repair the equipment by yourself, unless it is clearly specified in the manual. Please keep the equipment clean; if necessary, wipe the equipment with soft cotton cloth. In the following cases, please immediately cut off the power supply and contact our company: Water gets into the equipment; Equipment damage or shell breakage; Abnormal operation of equipment or its performances have completely changed; The equipment emits odor, smoke or abnormal noise. ...
-
Page 4: Table Of Contents
KIEN1005G User’s Manual 201106 Contents 1. Packing List ................................... 5 2. Product Overview................................ 5 3. Structure and Interface .............................. 5 4. Mounting .................................... 6 5. Cable Connection ................................ 1 0 6. LED Indicators ................................... 1 4 7. Product Models.................................. 1 4 8. Basic Features and Specifications .......................... 1 5 ... -
Page 5: Packing List
KIEN1005G Industrial Ethernet Switch 1 Hardware Installation Manual 1 ... -
Page 6: Mounting
KIEN1005G User’s Manual 201106 Top Panel 1: Terminal block for power input 2: Screw hole for grounding 4. Mounting Dimension Drawing for DINRail Mounting (Unit: mm) Dimension Drawing for Wall Mounting (Unit: mm) ... - Page 7 Step 2: Insert the top of the DIN‐Rail into the spring‐supported slot of the DIN‐Rail connecting seat in the rear panel of KIEN1005G as seen below; move the device in the direction of arrow 2 to put the whole Din‐Rail into the seat; check whether KIEN1005G is ...
- Page 8 KIEN1005G User’s Manual 201106 Remove KIEN1005G from DINRail The specific steps are as follows: Step 1: Plug the screwdriver into the hole at the bottom of spring locking plate; press the plate down to loosen the connection of DIN‐Rail and switch, as shown in arrow 1 Step 2: Take up KIEN1005G in the direction of arrow 2; meanwhile remove the device from the DIN‐Rail along the direction of arrow 3. KIEN1005G Wall Mounting The specific steps are as follows: Step 1: Select the mounting position for KIEN1005G on the wall or in cabinet; ensure that there is enough space for the switch. ...
- Page 9 KIEN1005G User’s Manual 201106 Step 2: Drill 4 holes on the selected position according to the wall mounting dimension drawings; use a cross‐screwdriver to screw 4 cross‐slot screws (M3×10) into holes. Don’t tighten up the screws completely; leave about 5mm of space between. Step 3: Aim 4 mounting holes on KIEN1005G mounting plate at 4 fixed screws; pass the screws through 4 holes with the diameter of 6.5mm (Ф6.5); then slide down KIEN1005G as seen below; finally screw 4 screws tightly. Now the KIEN1005G should be firmly fixed to the wall or cabinet. Remove KIEN1005G from wall or cabinet The specific steps are as follows: Step 1: Use a screwdriver to loosen 4 screws; move the device up to let screws into 4 holes with the diameter of 6.5mm (Ф6.5). ...
-
Page 10: Cable Connection
KIEN1005G User’s Manual 201106 5. Cable Connection RJ45 Port RJ45 port cable types and requirements 10/100/1000Base‐TX Ethernet RJ45 port can be connected to terminal equipment and network devices with straight‐through cables or cross‐over cables. RJ45 connectors must be equipped at both ends of cable. ... - Page 11 KIEN1005G User’s Manual 201106 1000M straightthrough cable wiring 1000M crossover cable wiring Power According to the power input requirements, use a 5.08mm‐spacing terminal block to connect power cable. ...
- Page 12 KIEN1005G User’s Manual 201106 5 pin 5.08mm power terminal block: Contact definition Contact number DC wiring definition AC wiring definition 1 PWR1: + PWR1: L 2 PWR1: ‐ PWR1: N 3 Protection Ground Protection Ground 4 PWR2: ‐ PWR2: N 5 PWR2: + PWR2: L Wiring and mounting Step 1: Take the power terminal block off KIEN1005G Step 2: Insert the power cable into the terminal block and fix the power cable Step 3: Put the terminal block back to KIEN1005G with the connected cable Grounding Chassis grounding and power terminal grounding ...
- Page 13 KIEN1005G User’s Manual 201106 There is a grounding screw on the top panel of the KIEN1005G, which is for chassis grounding. One end of the chassis grounding cable is connected with the grounding screw and the other end of the cable is reliably earthed. (The cross section area of chassis ...
-
Page 14: Led Indicators
KIEN1005G User’s Manual 201106 ... -
Page 15: Basic Features And Specifications
KIEN1005G User’s Manual 201106 Model Description Power 5 10/100/1000Base‐TX RJ45 12VDC, 24VDC/AC, dual KIEN1005G‐5GE Ports redundant power inputs 8. Basic Features and Specifications Standard IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z Industrial Standard EMI: FCC CFR47 Part 15, EN55022/CISPR22, Class A EMS: IEC61000‐4‐2(ESD): ±8KV (contact), ±15KV (air) IEC61000‐4‐3(RS): 10V/m (80MHz‐2GHz) IEC61000‐4‐4(EFT): Power Port: ±4KV; Data Port: ±2KV IEC61000‐4‐5(Surge) Power Port: ±2kV/DM, ±4kV/CM; Data Port: ±2kV ... - Page 16 KIEN1005G User’s Manual 201106 Power input: 12VDC (9~36VDC), 24VDC/AC (18~72VDC, 13~50VAC) Power terminal: 5‐pin 5.08mm‐spacing plug‐in terminal block Power consumption: full load: 3.4W; standby: 0.99W Physical Charactreristics Installation: DIN‐Rail or wall mounting Dimensions (W×H×D): 30mm×115mm×91.5mm Weight: 0.76Kg Environment Limits Operating Temperature: ‐40℃ to 85℃ (‐40 to 185℉) Storage Temperature: ‐40℃ to 85℃ (‐40 to 185℉) Ambient Relative Humidity: 5% to 95% (non‐condensing) MTBF: 357000h Warranty: 5 years For more information about KYLAND products, please visit our website: http://www.kyland.cn/ ...
