KYLAND Technology SICOM3000GPT Hardware Installation Manual

Industrial ethernet switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SICOM3000GPT/SICOM6000GPT
Industrial Ethernet Switch
Hardware Installation Manual
Publication Data: Apr. 2013
Version: V1.0
No.: 1.12.02.01
-0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SICOM3000GPT and is the answer not in the manual?

Questions and answers

Related Manuals for KYLAND Technology SICOM3000GPT

Summary of Contents for KYLAND Technology SICOM3000GPT

  • Page 1 SICOM3000GPT/SICOM6000GPT Industrial Ethernet Switch Hardware Installation Manual Publication Data: Apr. 2013 Version: V1.0 No.: 1.12.02.01...
  • Page 2 SICOM3000GPT/SICOM6000GPT Industrial Ethernet Switch Hardware Installation Manual Disclaimer: Kyland Technology Co., Ltd. tries to keep the content of this manual as accurate and as updated as possible. This document is not guaranteed to be error-free, and we reserve the right to amend it without notice to users.
  • Page 3 Notice for Safety Operation The product performs reliably as long as it is used accord- ing to the guidance. Artificial damage or destruction of the device should be avoided. Before using the device, read this notice carefully for personal and equipment safety. Please keep the manual for further reference.
  • Page 4 ● Do not operate the device or connect or disconnect cables during an electrical storm. ● Use compatible connectors and cables. If you are not sure, contact our sales or technical support personnel for confirmation. ● Do not disassemble the device by yourself. When an anomaly occurs, contact our sales or technical support personnel.

  • Page 5: Table Of Contents

    Contents 1 Product Overview 2 Structure and Interface 2.1 Front Panel 2.2 Rear Panel 2.2.1 1U Interface Module 2.2.2 0.5U Interface Module 3 Interface Module Installation 3.1 Mounting Modes and Steps 3.1.1 Installing Mounting Brackets 3.1.2 Inserting a 0.5U Interface Module into an Upper Slot (Slot 2, Slot 4, or Slot 6) 3.1.3 Inserting a 0.5U Interface Module into a Lower Slot (Slot 3, Slot 5, or Slot 7)
  • Page 6 5.7 Power Terminal Block 5.8 Alarm Terminal Block 6 LEDs 7 Switch Access 7.1 Access through Console Port 7.2 Access through Telnet 7.3 Access through Web 8 Basic Features and Specifications...

  • Page 7: Product Overview

    Product Overview 1 Product Overview The series switches include layer-2 SICOM3028GPT/3424PT/ 3028GP/3424P switches and layer-3 SICOM6028GPT/6424PT/ 6028GP/6424P switches. With modular design, all these switches support IRIG-B, GPS, and serial port modules for easy expansion. Based on the full gigabit switching platform, the series switches are the first industrial Ethernet switches that employ the IEC61850 modeling technology in the world, achieving unified management.
  • Page 8 Product Overview Table 1 Models...
  • Page 9 Product Overview Table 2 Interface Modules...
  • Page 10 Product Overview Continued on the table...
  • Page 11 Product Overview Table 3 Other Modules Note: For the product information listed in these tables, we reserve the right to amend it without notice. To obtain the latest information, you can contact our sales or technical support personnel.

  • Page 12: Structure And Interface

    Structure and Interface 2 Structure and Interface Caution: It is recommended to purchase the port dustproof shield (optional) to keep ports clean and ensure device performance. 2.1 Front Panel (1)(3)(5) (2)(4)(6) Figure 1 Front Panel Table 4 Description of the Front Panel...

  • Page 13: Rear Panel

    Structure and Interface 2.2 Rear Panel (8)(9) (10) Figure 2 Rear Panel Table 5 Description of the Rear Panel Identifier Description Slot 1 for 1U interface module Slot 2 for 0.5U interface module Slot 3 for 0.5U interface module Slot 4 for 0.5U interface module Slot 5 for 0.5U interface module Slot 6 for 0.5U interface module Slot 7 for 0.5U interface module...

  • Page 14: Interface Module

    Structure and Interface 2.2.1 1U Interface Module SM6.6-4GX-1U 1-4: four 1000Base-X, 10/100/1000Base-T (X)SFP slots Figure 3 SM6.6-4GX-1U SM6.6-2GX-2GE-1U 1-2: two 10/100/1000Base-T(X) Ethernet ports 3-4: two 1000Base-X, 10/100/1000Base-T (X)SFP slots Figure 4 SM6.6-2GX-2GE-1U SM6.6-4GE-1U 1-4: four 10/100/1000Base-T(X) Ether- net ports Figure 5 SM6.6-4GE-1U...

  • Page 15: U Interface Module

    Structure and Interface 2.2.2 0.5U Interface Module SM6.6-4GX-0.5U Figure 6 SM6.6-4GX-0.5U 1-4: four 1000Base-X, 10/100/1000Base-T(X)SFP slots SM6.6-2GX-2S/M-0.5U Figure 7 SM6.6-2GX-2S/M-0.5U 1-2: two 100Base-FX Ethernet ports (FC/ST/SC connector) 3-4: two 1000Base-X, 10/100/1000Base-T(X)SFP slots...
  • Page 16 Structure and Interface SM6.6-4GE-0.5U Figure 8 SM6.6-4GE-0.5U 1-4: four 10/100/1000Base-T(X) Ethernet ports (Note: Its appearance is identical with that of SM6.6-4T-0.5U. You can distinguish them by labels on the front panel.) SM6.6-2GX-2GE-0.5U Figure 9 SM6.6-2GX-2GE-0.5U 1-2: two 10/100/1000Base-T(X) Ethernet ports 3-4: two 1000Base-X, 10/100/1000Base-T(X)SFP slots...
  • Page 17 Structure and Interface SM6.6-4S/M-0.5U Figure 10 SM6.6-4S/M-0.5U 1-4: four 100Base-FX Ethernet ports (FC/ST/SC connector) SM6.6-2S/M-2T-0.5U Figure 11 SM6.6-2S/M-2T-0.5U 1-2: two 10/100Base-T(X) Ethernet ports 3-4: two 100Base-FX Ethernet ports (FC/ST/SC connector)
  • Page 18 Structure and Interface SM6.6-4T-0.5U Figure 12 SM6.6-4T-0.5U 1-4: four 10/100Base-T(X) Ethernet ports (Note: Its appearance is identical with that of SM6.6-4GE-0.5U. You can distinguish them by labels on the front panel.) SM6.6-GPS-OI-0.5U For details, refer to the GPS Clock Synchronization Module Hardware Installation Manual.

  • Page 19: Interface Module Installation

    Interface Module Installation 3 Interface Module Installation Caution: Power off the switch before you install or remove an interface module. 3.1 Mounting Modes and Steps The series switches provide one 1U slot (Slot 1) and six 0.5U slots (Slot 2-Slot 7) on the rear panel, as shown in Figure 2. You can install interface modules as needed.

  • Page 20: Installing Mounting Brackets

    Interface Module Installation 3.1.1 Installing Mounting Brackets Before inserting a 0.5U interface module into an upper or lower slot, install mounting brackets on the module as follows: Select an applicable 0.5U interface module. Insert two mounting brackets into the screw holes at both sides of the module. Push the brackets in direction 1 until the brackets are firmly secured to the module.

  • Page 21: Inserting A 0.5U Interface Module Into An Upper Slot (Slot 2,Slot 4, Or Slot 6)

    Interface Module Installation 3.1.2 Inserting a 0.5U Interface Module into an Upper Slot (Slot 2,Slot 4, or Slot 6) Step 1:Insert the guide rail of the interface module into the guide rail slot with "TOP" facing up. Then push the module into the slot along the guide rail slot until it is in position.

  • Page 22: Inserting A 0.5U Interface Module Into A Lower Slot (Slot 3, Slot 5, Or Slot 7)

    Interface Module Installation 3.1.3 Inserting a 0.5U Interface Module into a Lower Slot (Slot 3, Slot 5, or Slot 7) Step 1:Insert the guide rail of the interface module into the guide rail slot with "TOP" facing down. Then push the module into the slot along the guide rail slot until it is in position.

  • Page 23: Dismounting

    Interface Module Installation 3.1.4 Inserting a 1U Interface Module into Slot 1 The steps for inserting a 1U interface module into Slot 1 is the same as those for inserting a 0.5U interface module into an upper slot (Slot 2, Slot 4, or Slot 6).

  • Page 24: Removing A 1U Interface Module

    Interface Module Installation 3.2.2 Removing a 1U Interface Module Step 1:Remove the three screws(M2.5×6) securing the module to the switch. Step 2: Pull out the module by holding the handle until the module is completely detached from the slot. Handle Figure 17 Removing a 1U Interface Module...

  • Page 25: Switch Installation

    Switch Installation 4 Switch Installation 4.1 Dimension Drawing 482.6 Figure 18 Dimensions (unit:mm) Caution: As part of the heat dissipation system, the switch housing becomes hot during operation. Please use caution when coming in contact and avoid covering the switch housing when the switch is running.

  • Page 26: Mounting Modes And Steps

    Switch Installation 4.2 Mounting Modes and Steps The series switches support rack mounting by front/rear panel. The following uses mounting by front panel as an example to describe mounting steps. The steps for mounting by rear panel are similar to those for mounting by front panel.
  • Page 27 Switch Installation You can select the screw holes for front or rear panel mounting to install the mounting brackets. If there are screws inserted in the screw holes, remove the screws and keep them for future use. As shown in the following figure, use four screws to secure two mounting brackets to the switch respectively.
  • Page 28 Switch Installation Mounting Step 1: Select the mounting position for the switch and guarantee adequate space and heat dissipation (dimensions: 440mm×44mm× 360mm). Step 2: Move the switch in direction 1 until the screw holes for securing the mounting brackets to rack posts are in alignment with the corresponding holes in the rack posts.

  • Page 29: Connection

    Connection 5 Connection 5.1 10/100Base-T(X) Ethernet Port 10/100Base-T(X) Ethernet port is equipped with RJ45 connector. The port is self-adaptive. It can automatically configure itself to work in 10M or 100M state, full or half duplex mode. The port can also adapt to MDI or MDI-X connection automatically.
  • Page 30 Connection Wiring Sequence RJ45 connector RJ45 connector Straight-through cable Wiring sequence Cross-over cable Wiring sequence Figure 23 Connection Using Straight-through/Cross-over Cable Note: The color of the cable for RJ45 connector meets the 568B standard: 1-orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8- brown.

  • Page 31: 100Base-Fx Ethernet Port

    Connection 5.2 100Base-FX Ethernet Port 100Base-FX Ethernet port is equipped with FC/ST/SC connector, and each port consists of TX (transmit) port and RX (receive) port. To enable data transmission between Device A and Device B, connect the TX port of Device A to the RX port of Device B, and the RX port of Device A to the TX port of Device B.

  • Page 32: 10/100/1000Base-T(X) Ethernet Port

    Connection 5.3 10/100/1000Base-T(X) Ethernet Port 10/100/1000Base-T(X) Ethernet port is equipped with RJ45 connec- tor. The port is self-adaptive. It can automatically configure itself to work in 10M, 100M, or 1000M state, full or half duplex mode. The port can also adapt to MDI or MDI-X connection automatically. You can connect the port to a terminal or network device with a straight- through or cross-over cable.
  • Page 33 Connection Wiring Sequence RJ45 connector RJ45 connector Straight-through cable Wiring sequence Cross-over cable Wiring sequence Figure 26 Connection Using Straight-through/Cross-over Cable Note: The color of the cable for RJ45 connector meets the 568B standard: 1-orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green, 7-brown and white, and 8- brown.

  • Page 34: 1000Base-X, 10/100/1000Base-T(X)Sfp Slot

    Connection 5.4 1000Base-X, 10/100/1000Base-T(X)SFP Slot 1000Base-X, 10/100/1000Base-T(X) SFP slot (gigabit SFP slot) requires an SFP optical/electrical module to enable data transmis- sion. The following table lists the gigabit SFP optical/electrical modules (optional) supported by the series switches. Table 8 Gigabit SFP Optical/Electrical Modules...

  • Page 35: Gigabit Sfp Optical Module

    Connection 5.4.1 Gigabit SFP Optical Module Figure 27 Gigabit SFP Optical Module An SFP optical module is equipped with LC connector, and each port consists of a TX (transmit) port and an RX (receive) port. To enable communication between Device A and Device B, connect the TX port of Device A to the RX port of Device B, and the RX port of Device A to the TX port of Device B, as shown in the following figure.
  • Page 36 Connection How to Connect the SFP Optical Module Insert the SFP optical module into the SFP slot in the switch, and then insert the fibers into the TX port and RX port of the SFP module. SFP slot SFP optical module Optical fiber Figure 29 Connecting the SFP Optical Module Identify the RX port and TX port of an SFP optical module:...

  • Page 37: Gigabit Sfp Electrical Module

    Connection 5.4.2 Gigabit SFP Electrical Module Figure 30 Gigabit SFP Electrical Module How to Connect the SFP Electrical Module Insert the SFP electrical module into the SFP slot in the switch, and then insert the RJ45 connector of the twisted pair into the SFP module. SFP slot SFP Electrical module RJ45 connector...

  • Page 38: Console Port

    Connection 5.5 Console Port The console ports support RJ45 and Mini USB connectors. You can select either of the two connectors as needed. If you select Mini USB connector for one port and RJ45 connector for the other, only the console port with the Mini USB connector works when both of the two ports are connected.
  • Page 39 Connection DB9-RJ45 Console Cable One end of a DB9-RJ45 console cable is the DB9 connector to be inserted into the 9-pin serial port of a PC, and the other end is crimped RJ45 connector to be inserted into the console port of the switch. Facing the A direction Facing the B direction RJ45 connector...
  • Page 40 Connection One end of a USB console cable is Mini USB connector to be inserted into the console port of the switch, and the other end is the USB connector to be inserted into the USB port of a PC. 1 2 3 4 5 Figure 34 Mini USB Connector Table 10 Pin Definitions of the Mini USB Connector...

  • Page 41: Grounding

    Connection 5.6 Grounding Grounding protects the switch from lightning and interference. There- fore, you must ground the switch properly. You need to ground the switch before it is powered on and disconnect the grounding cable after the switch is powered off. The switch provides a grounding screw on the rear panel for chassis grounding.

  • Page 42: Power Terminal Block

    Connection 5.7 Power Terminal Block There is a power terminal block on the rear panel of the device. You need to connect the power wires to the terminal block to provide power to the device. The device supports single (PWR1) and redun- dant (PWR1 and PWR2) power supply with a 5-pin 5.08mm-spacing plug-in terminal block.
  • Page 43 Connection The following table lists the pin definitions of the 5-pin 5.08mm- spacing plug-in terminal block. Table 12 Pin Definitions of 5-Pin 5.08mm-Spacing Plug-in Terminal Block Signal DC Definition AC Definition PWR1: + PWR1: L PWR1: - PWR1: N PGND PGND PWR2: - PWR2: N...
  • Page 44 Connection PGND PWR2: -/N PWR1: -/N PWR2: +/L PWR1: +/L Plug Socket Figure 38 Connection of 5-Pin 5.08mm-Spacing Plug-in Terminal Block Caution: The switch supports 24DC, 48DC, and 220AC/DCW power input. Before connecting the device to power supply, make sure that the power input meets the power requirement. If connected to an incorrect power input, the device may be damaged.

  • Page 45: Alarm Terminal Block

    Connection 5.8 Alarm Terminal Block The device provides an alarm terminal block on the rear panel for alarm output. When the switch works properly, the normally-open contacts of the alarm relay are closed and the normally-closed contacts are open; when an alarm occurs, the normally-open contacts are open and the normally-closed contacts are closed.

  • Page 46: Leds

    LEDs 6 LEDs Table 13 Front Panel LEDs...
  • Page 47 LEDs Continued on the table...
  • Page 48 LEDs Table 14 Rear Panel LEDs Speed Connection status Speed Connection status...
  • Page 49 LEDs Caution: The speed LEDs of 100M ports on the front and rear panels of SICOM3028GPT, SICOM3028GP, SICOM6028GPT, and SICOM6028GP are never on. When SM6.6-GPS-OI-0.5U and SM6.6-PTP-BO-0.5U are in use, the LEDs for the slots where the two modules reside are off. When SM6.6-4D-232/422/485-0.5U is in use, the LEDs (with identifier "4") for the slot where the module resides are on.

  • Page 50: Switch Access

    Switch Access 7 Switch Access You can access the switch in any of the following ways: 7.1 Access through Console Port Caution: The console ports support RJ45 and Mini USB connectors. You can select either of the two connectors as needed.If you select Mini USB connector for one port and RJ45 connector for the other, only the console port with the Mini USB connec- tor works when both of the two ports are connected.
  • Page 51 Switch Access Step 3: Create a connection "Switch", as shown in the following figure. Figure 40 Creating a Connection Step 4: Connect the communication port in use, as shown in the following figure. Figure 41 Selecting a Serial Port Note: To confirm the communication port in use, right-click [My Computer] and select [Property].
  • Page 52 Switch Access Step 5: Set port parameters (Bits per second: 115200, Data bits: 8, Parity: None, Stop bits: 1, and Flow control: None), as shown in the following figure. Figure 42 Setting Port Parameters Step 6: Click OK to enter the switch CLI. Then the following commands can be used to perform operations.

  • Page 53: Access Through Telnet

    Switch Access 7.2 Access through Telnet Step 1:Connect the network port of a PC to the Ethernet port of the switch with a network cable. Step 2:On the Windows desktop, click Start and Run. The Run dialog box is displayed. Enter "telnet IP address". For example, if the IP address of the serial port module is 192.168.0.2 (default IP address of the device), enter "telnet 192.168.0.2"...

  • Page 54: Basic Features And Specifications

    Basic Features and Specifications 8 Basic Features and Specifications...
  • Page 56 FAX: +86-10-88796678 Website: http://www.kyland.com Email: support@kyland.com For more information about KYLAND products, please visit our website: http://www.kyland.com...
