bers. Some applications specify a range of ports in which case you will need to know
both the starting and ending port numbers in the range, which are mapped by the
start port and end port fields.
The Destination Port Map field specifies the internal port that the data will be
directed to on the LAN Client. When dealing with port ranges, the Internal Port (des-
ignated by the Port Map field) will be the same as the first port in the range. When
you simply want to forward a single port from outside (i.e. WAN side) to inside (i.e.
LAN side), then all three fields (Port Start, Port End and Port Map) will have the
same port number.
Option
Con­n­ection­:
Application­:
Protocol:
Option
Source IP Address:
Source Netmask:
Destin­ation­ IP Address:
Destin­ation­ Netmask:
NB5Plus4/W User Guide
5
Description
Choose the connection to which the rule
is to be applied to.
Provide a name for the application (e.g.
Azureus). The name must be unique,
must not contain spaces and cannot
begin with a number.
Can be either TCP or UDP, or both.
Description
The client on the Internet sending the
data (e.g. 202.44.55.66). Note, if you
do not know the IP address of the client
use 0.0.0.0 for any client on the Inter-
net.
The subnet mask of the client connect-
ing to you. Note, if you do not know the
Netmask use 0.0.0.0.
The LAN IP address of the device on
your network to which packets of data
will be forwarded to (e.g. 192.168.1.2).
The subnet mask of the LAN device.
