SAGEMCOM F@ST 4310 Reference Manual page 98

5- Information / Configuration
5.7.8.1 Queue Config
Object: This menu is used to enable or disable QoS on an interface, and to configure QoS to use policy
maps attached to an interface.
• In the Advanced Setup menu, select Quality of Service then select QoS Queue.
The following screen opens:
Field
Name
Key
Interface
Scheduler Alg
Precedence
DSL Latency
PTM Priority
Enable
Remove
a. This field appears only if the DSL mode selected is IPOA.
Page 5-66
Queue entry name
Sequence number allocated by the system, incremented of a unit
to each addition of a QoS Queue.
Name of the network interface configured (8/32 for example).
Scheduler algorithm allocated to this queue.
Priority allocated to "Queue Precedence" from 1 to 3.
DSL Latency
a
PTM priority
QoS enabled or disabled for this interface.
Note: This status can be amended starting from this window.
Check the box and click on the [Remove] button to remove the
queue from this list.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
State
F@ST 4310 Reference Manual
