SAGEMCOM F@ST 4310 Reference Manual page 59

Field
Inactivity Timeout
(minutes):[1-4320]
PPP retry on
authentication error
PPP retry period
(seconds) ):[3-65535]
PPP MTU (Bytes)
Use Static IPv4 Address
c
IPv4 Address
Enable PPP Debug
mode
Bridge PPPoE frames
between WAN and Local
Ports
Enable IGMP Multicast
Proxy
a. This field only appears when the "PPP retry on authentication error" field is activated (box checked).
b. This field only appears when the "PPP retry on authentication error" field is activated (box checked).
c. This field only appears when the "Use Static IPv4 Address" field is activated (box checked).
• Click on the Next button to continue configuring the remote network (WAN) in PPPoE mode.
F@ST 4310 Reference Manual
Enter the inactivity time. This value (in minutes) is between 1
and 4320 (i.e. 72 hours).
a
If there is no Internet traffic for this period of time, the PPPoE
session is interrupted.
Check the box, PPP can be retried again and again while
authentication fails.
Enter if required a retry period. This value (in seconds) is by
default set to 15 seconds. You can set another value from 3 to
b
65535.
Enter an MTU (Maximum Transfer Unit) value. This value (in
bytes) is between 38 and 1492.
Note: The MTU specifies the maximum size of the data used
(IP packets) expressed as a number of bytes.
Check the box to use the static IPv4 address.
Enter the static IPv4 address.
Check the box to use the PPP Debug mode.
In the event of connection failure, this option will enable you to
trace a possible problem in the SYSLOG file.
Check the box to enable the router when bridging the frames
between WAN and local Ethernet ports.
Check the box to activate the IGMP function.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
5- Information / Configuration
Action
Default
value
0
Checked
15
1492
Not
checked
0.0.0.0
Not
checked
Not
checked
Not
checked
Page 5-27
