5.11.4 TR-069 Client
Object: The TR-069 protocol (WAN Management Protocol) is used, via a remote server
(Auto-Configuration Server (ACS)) to auto configure your router, provide it with certain services
and manage it by establishing "diagnostics".
• In the Management menu, select TR-069 Client.
The following screen opens:
Field
Inform
Inform Interval
ACS URL
ACS User Name
ACS Password
WAN Interface used
by TR-069 client
Display SOAP
Messages on serial
console
Connection Request
Authentication
Connection Request
User Name
Connection Request
Password
Customize
Connection Request
URL Port
• Click on the Get RPCMethods button to launch the auto-configuration procedure of your router.
F@ST 4310 Reference Manual
Check the Enable box to activate the "TR-069" or Disable to
deactivate it.
Enter a time interval between two pieces of information sent
from the router to the ACS server.
This interval is a value (in seconds).
Enter the URL or the IP address of the ACS server.
Enter the name of the user of the ACS server.
Enter the ACS server password.
Select in the scroll down list the desired WAN interface.
Check the Enable box to activate it or Disable to deactivate it.
Check the box to activate authentication or uncheck it to
deactivate it.
Enter the name of the user of your router.
Enter your password for your router.
Enter the port to use for Connection request from the ACS.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
5- Information / Configuration
Action
Default
value
Disable
300
-
admin
admin
Any_WAN
Disable
Checked
admin
admin
7547
