SAGEMCOM F@ST 4310 Reference Manual page 90

5- Information / Configuration
Add
• Click on the Add button to display the following screen:
Field
Filter Name
IP Version
Protocol
Source IP
address[/prefix
length]
Source Subnet Mask
Source Port
(port or port:port)
Destination IP
address[/prefix
length]
Destination Port
(port or port:port)
Page 5-58
Enter a representative name for the filter.
Select the dedicated IP version from the scroll down list (for example:
IPv4).
Select the dedicated protocol from the scroll down list (TCP/UDP, TCP,
UDP, ICMP).
Enter the Source IP address (LAN).
Subnet Mask.
Enter a "Source" port (LAN) or range of ports.
Note: For one port, for example, enter 80.
For a range of ports, enter 80:90.
Enter the Destination IP address (WAN).
Enter a "Destination" port (WAN) or range of ports.
Note: For one port, for example, enter 80.
For a range of ports, enter 80:90.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Action
F@ST 4310 Reference Manual
